Ironpie m6 USER MANUAL
Safety Regulations Before using this product, please read and follow all the following safety instructions, and keep this manual for future reference. Any operation inconsistent with this instruction manual may cause damage to this product. Note: 1． Only authorized technicians can disassemble this product. Users are not recommended to disassemble this product by themselves. 2． This product can only use the power adapter provided by the factory. If other adapters are used, the product may be damaged.
Contents Product Composition / Package Contents 3 Product Composition / Parts 4 Product Usage / Preparation 6 Product Usage / Charging 7 Product Usage / Start Cleaning 8 Product Usage / Pause, Recharge, and Shutdown 8 Product Usage / App Installation and Setting 9 Component Maintenance / Dustbin 11 Component Maintenance / Main Brush and Side Brush 14 Component Maintenance / Charging Pole Piece, Cliff Sensor, Drive Wheel, and Caster Wheel 15 Investigation of Common Issues 16 Indicator
Product Composition / Package Contents Robot Charging Base Power Adapter Instructions Package Cleaning Brush L Dustbin Instructions Package R Side Brush High Efficiency Filter 3
Product Composition / Parts Back View Front View Cliff Sensor Side Brush Power Button Drive Wheel Recharge Button Camera Dustbin Surface Cover Omnidirectional Lens Dustbin Button Charging Pole Piece Caster Wheel Battery Main Brush Assembly
Dustbin Charging Base Signal Indicator High Efficiency Strainer High Efficiency Net Cover Primary Filter Strainer Dustbin Metal Sheet Dustbin Conductive Sheet Dustbin Side Cover DC Plug Charging Pole Piece
Product Usage / Preparation Remove Protection Before using the robot, remove the protective strip on the robot and the protective film on the charging base.
Product Use / Charging 1. Place and charge: the charging base should be placed against the wall and on the flat ground. Do not place any items within the range of 0.5m left and right and 1.5m ahead. 2. Connect to the power supply. 3. Install the side brush: on the left and right (L/R). 4．Charging: place the robot on the charging base for charging. (The charging cycle takes about 5 hours.
Product Use / Start Cleaning Based on your home environment, the robot will perform cleaning with a “zigzag” path to cover your home. Setting method: When the robot is powered off, long press the Power button. After the start music is played which indicates the robot is powered on, short press the Power button, and the robot will start cleaning automatically. Product Use / Pause, Recharge, and Shutdown Pause: When the robot is cleaning, press the Power button to pause the cleaning.
Product Usage / App Installation and Settings Search the “Trifo Home” app in iOS App Store or Android Play Store, download, and install. Please make sure your phone is connected to 2.4GHz and 802.11b/g/n bands Wi-Fi router. 1. Open the “Trifo Home”, create an account with your email address or your phone number; 2. Click “+” to add device; 3. Select the product model you want to add; 4.
5. Enter the Wi-Fi password, then click “Next”; 6. A QR code will be generated on your smartphone. Please make sure the QR code facing towards the robot vacuum's camera. After hearing the confirmation tone of scanning QR code successfully, click “Next”; 7. Please wait for the connection process. It will take about 2 minutes; 8. The robot and app will both give hints to inform the connection is successful. Name your robot in the app, and the setting process is completed.
Component Maintenance / Dustbin A. Press the dustbin button to remove the dustbin. C. Empty the dustbin. B. Open the side cover of the dustbin. D. Open the high efficiency net cover.
E．Open the high-efficiency screen cover, take out the high-efficiency screen and the primary-efficiency screen, and tap gently against the trash container to remove the debris. It is not recommended to wash the high-efficiency screen. F．Rinse the primary filter screen. G．Scrub the dustbin with a cloth. Please do not let water seep into the fan port during cleaning.
H．Dry the dustbin and filters, and keep it dry to maximize its lifespan. Note: It is recommended to wash the primary strainer with water 15 - 30 days after it is used. The maximum lifespan of the high efficiency filter screen is 3 months. I. Put the primary filter screen and the high efficiency filter screen back into the dustbin. Note: 1. Before installing the filter screen, please ensure that the high efficiency filter screen and the primary filter screen are dry. 2.
Component Maintenance / Main Brush and Side Brush 1. Open the main brush cover. 3. Clean the tangled hair. Cleaning main brush 2. Take out the main brush shaft.
Component Maintenance / Charging Pole Piece, Cliff Sensor, Drive Wheel, and Caster Wheel Tips: The interior of the charging pole piece, the cliff sensor and the bumper contain sensitive electronic components. Please use dry cloth to clean. Please prevent any water contact or using a wet cloth to clean. Clean the charging pole piece. Clean the drive wheels and the caster wheel. Clean the cliff sensor. * If you do not use the robot for a long time, please fully charge it before storing it.
Investigation of Common Issues Prompt Tone Solution Transport robot back to dock Plug in power to charging base; Place charging base as instructed; Move robot close to charging base. Drive wheel not on surface Please put the robot back to the ground and press the Power button again. Drive wheel stuck Check whether the drive wheel is entangled with objects and clean it up. Side brush stuck Check if the side brush is entangled and clean it up.
Dustbin missing Put the dustbin back to the robot correctly. Dustbin full Clean dustbin. Charging error Check if the battery is installed correctly before being recharged. Please make sure the robot could be powered on. If any abnormal sign happens during recharging, it may be either robot or charging base displaced. Front wheel stuck Check if the the caster wheel can move freely to all directions. If not, please remove the screws and clean the wheel.
Indicator Lights Explanation Indicator Light 18 Robot Working Status Power button solid green Normal working mode Power button solid green and recharge button flashing yellow Battery low Power button solid green and recharge button solid yellow Looking for charging base Recharge button solid yellow Recharging Power button flashing green and recharge button flashing yellow alternately Network configuration mode Power button solid red Malfunction
Product Specifications Classification Physical size Battery Cleaning System Projects Parameter Diameter 330 mm Height 74 mm Net weight 2.7 kg Voltage 14.4 volts Battery 2500 mAh rechargeable lithium battery pack Dustbin capacity 600 ml Each charging period about 300 minutes Each cleaning period about 100 minutes Rated power 28 watts Operating voltage 14.4 volts * This information is subject to change, and Trifo reserves the right to update the product specifications.
Harmful Substance Component Pb/Pb compound Hg/Hg compound Cd/Cd compound Cr(VI)Cr(VI) compound PBB PBDE Plastic Hardware Host circuit module Electronic Battery Plug power cord (Metal part) Description: This form is prepared in accordance with the provisions of SJ/T 11364. 〇 : Indicates that the content of the hazardous substance in all homogeneous materials of the part is below the limit requirement specified in the current valid version of GB/T26572.
Customer Service 12 months Limited Warranty Lifetime Technical Support support@trifo.
For FAQs and more information, please visit: www.trifo.
