INFINITY
®
35-6/55-6 SERIES GOLF ROTORS
INFINITY 35-6 SERIES PERFORMANCE CHART
Base
Pressure
Nozzle Set 30
(White)
Nozzle Set 31
(Yellow)
Nozzle Set 32
(Blue)
Nozzle Set 33
(Brown)
Nozzle Set 34
(Orange)
Nozzle Set 35
(Green)
Nozzle Set 36
(Gray)
Nozzle Set 37
(Black)
102-2208 102-4587 102-4588 102-4589 102-0728 102-0729 102-0730 102-4261
Blue Gray Blue Gray Red Gray Orange Gray Orange Gray Blue Gray Blue Gray Orange Gray
102-2925 102-2910 102-2925 102-2910 102-2928 102-2910 102-2926 102-2910 102-2926 102-2910 102-2925 102-2910 102-2925 102-2910 102-2926 102-2910
Back
Nozzle
Positions
Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug
102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335
psi Radius gpm Radius gpm Radius gpm Radius gpm Radius gpm Radius gpm Radius gpm Radius gpm
50 42 7.1 52 13.7 61 17.1 64 20.2 69 27.4
65 45 8.7 54 15.5 63 20.5 66 22.9 74 30.0 76 32.4
80 46 9.6 57 17.0 67 22.6 70 25.3 77 33.2 79 35.8 84 37.5 86 40.8
100 48 11.2 59 18.9 72 25.2 74 28.2 80 37.0 84 39.9 88 42.5 92 45.3
Stator 102-6929 Blue 102-1939 Yellow 102-1940 White
Conversions INF35-6-3134 INF35-6-3537
INFINITY 55-6 SERIES PERFORMANCE CHART
Base
Pressure
Nozzle Set 51
(Yellow)
Nozzle Set 52
(Blue)
Nozzle Set 53
(Brown)
Nozzle Set 54
(Orange)
Nozzle Set 55
(Green)
Nozzle Set 56
(Gray)
Nozzle Set 57
(Black)
Nozzle Set 58
(Red)
Nozzle Set 59
(Beige)
102-4587 102-4588 102-4589 102-0728 102-0729 102-0730 102-4261 102-4260 102-4259
Blue Gray Red Gray Orange Gray Orange Gray Blue Gray Blue Gray Orange Gray Blue Gray Blue Gray
102-2925 102-2910 102-2928 102-2910 102-2926 102-2910 102-2926 102-2910 102-2925 102-2910 102-2925 102-2910 102-2926 102-2910 102-2925 102-2910 102-2925 102-2910
Back
Nozzle
Positions
Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug
102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335
psi Radius gpm Radius gpm Radius gpm Radius gpm Radius gpm Radius gpm Radius gpm Radius gpm Radius gpm
50 52 13.9 62 17.4 66 20.7 69 28.6
65 54 15.7 64 20.8 68 23.4 74 31.2 76 33.8
80 57 17.2 68 22.9 72 25.8 77 34.4 79 37.2 85 39.4 89 43.6 92 47.5 96 57.0
100 59 19.1 73 25.5 76 28.7 80 38.2 84 41.3 89 43.7 94 48.5 95 51.1 100 61.1
Stator 102-1939 Yellow 102-1940 White 102-1941
Conver. INF55-6-5154 INF55-6-5558 INF55-6-59
Not recommended at these pressures. Radius shown in feet.
Toro recommends the use of a 1
1
4" swing joint at flows over 25-gpm (95-LPM). Sprinkler radius data collected in Toro’s zero wind test facility per ASAE standard S398.1.
Actual site conditions must be considered when selecting the appropriate nozzle.
All sprinklers are equipped with the selectable pilot valve that allows settings at 50, 65, 80 and 100 psi.
Main Nozzle Adapter
A wide assortment of
intermediate and inner
nozzles for use in the main
nozzle adapter and back
nozzle position provide
unmatched nozzle flexibility.
