Data Sheet

3
Rev. 2/21
The Groundsmaster 4000-D is manufactured
in Tomah, WI ISO 9002 Certified Plant.
Groundsmaster
®
4000-D Attachment Specifications
*
*Specifications and design subject to change without notice.
Note: The Toro Company does not manufacture or sell the snowthrower or rotary broom, nor does Toro guarantee these
accessories in any manner whatsoever.
ROTARY BROOM, MB MODEL HCT
TYPE
Windrow type, front mounted hydraulic broom with dual
motors. Electric/hydraulic angling, 30° left and right.
BROOM SIZE
32" (81 cm) diameter x 60" (153 cm) wide.
BRUSH
Sectional brush with combination polypropylene/wire radial
segments.
WEIGHT
460 lbs. (209 kg)
OPTIONS
Dirt Deflector, Storage Stands.
SUNSHADE
UNIVERSAL MOUNT SUNSHADE
White, Model 30669 / Red, Model 30671
SNOWTHROWER, ERSKINE MODEL 2000
STAGE
2
CLEARING WIDTH
61" (155 cm)
SNOW CUT DEPTH
29" (74 cm)
CUTTING EDGE
3/8" x 3" (9.5 mm x 7.6 cm) bolt-on
SKID SHOES
Adjustable
AUGER DIAMETER
16" (41 cm) open flight
FAN DIAMETER
20" (51 cm) 4-blade
CHUTE ROTATION
Hydraulic 270°
SHEAR PROTECTION
Pressure relief
THROWING DISTANCE
Up to 30' (9.14 m)
APPROXIMATE SHIPPING WT.
850 lbs. (386 kg)
HOSES
Included
TWO-POST ROPS EXTENSION SYSTEM
GM4000 MODELS
Fits Models 30605 or 30609
TWO-POST ROPS EXTENSION KIT
Base steel frame attached to existing ROPS and includes
a white sunshade. Model 31352
EXTERIOR MIRROR
Quantity (1) Part Number 130-5448
INTERIOR MIRROR
Quantity (1) Part Number 130-5449
ABRASION-RESISTANT
POLYCARBONATE WIND SCREEN
Improved resistance to golf ball impacts or vandalism.
Model 31324
TEMPERED GLASS WINDSHIELD
Similar safety glass used in Toro all-season safety cabs.
Model 31325
WINDSHIELD WIPER KIT FOR
TEMPERED GLASS WINDSHIELD
For use with the tempered glass windshield only. Not for
use with the polycarbonate wind screen. Model 31311
OPERATOR FAN & INTERIOR
HEADLINER KIT
Overhead fan with adjustable speeds – mounts directly
over operator. Part Number 132-3435
WIRE HARNESS KIT
Required for all electrical accessories such as wipers,
lights and fan. Part Number 122-0729
(GM5900 SHOWN)
