FieldSweep
™
660
*
The Bullseye FieldSweep 660 is a ground-driven surface
debris removal and grooming tool designed primarily
for synthetic turf fields. The counter rotating paddle
style brushes on the FieldSweep 660 lift surface debris
and infill material to be separated on the shaking sieve. The
infill is returned to the surface and brushed in while the unwanted debris continues
across the sieve to the easily removable collection bins on the rear of the unit. The tine section aids in decompaction while the rear brush grooms the
field surface to leave a clean, smooth and aesthetically pleasing finish. Optional accessories allow custimization for different types of infill material
and any tow vehicle.
BULLSEYE FIELDSWEEP 660, MODEL 46412
WORKING WIDTH
65.7” (167 cm)
WORKING DEPTH
Up to 0.4” (10 mm)
OPERATING SPEED
Up to 7.5 mph (12 km/h) depending on field conditions
MAXIMUM CAPACITY
216,810 sq. ft. (20,040 sq. meters) at maximum operating speed
TRACTOR REQUIREMENTS
550 lb. (250 kg) lift capacity, with 3-point category 1 hitch
UTILITY VEHICLE REQUIREMENTS
Minimum towing capacity 485 lbs. (220 kg), drawbar hitch and wheel kit required, model 46413
DEBRIS BIN CAPACITY
2X @ 1,220 cu. in. (2X @ 20 liters)
STANDARD SIEVE SIZE
0.196” x 0.196” (5 x 5 mm)
WEIGHT
485 lbs. (220 kg)
DIMENSIONS
Width 75.4” (191.5 cm) Height 29.5” (74.9 cm) Length 68.3” (173.4 cm)
WARRANTY
One-year limited warranty. Refer to the Operator’s Manual for further details.
BULLS EYE
™
™
BULLSEYE FIELDSWEEP 660 ACCESSORIES
DRAWBAR HITCH & WHEEL KIT
Allowing the ability to tow with utility vehicles, model 46413
MAGNET KIT
Able to remove metallic objects while cleaning surface debris, model 46414
0.126” SIEVE
0.126” x 0.126” (3.2 x 3.2 mm) sieve, part #144-7757
0.157” SIEVE
0.157” x 0.157” (4 x 4 mm) sieve, part # 144-7758
0.236” SIEVE
0.236” x 0.236” (6 x 6 mm) sieve, part # 144-7760
