Gas airsoft / cal. 6 mm operating instructions 2 - 10 mode d´emploi 11 - 19 manual de instrucciones 20 - 28 umareX holDs the WorlDWiDe eXclusiVe hKtraDemarK anD eXterior DesiGn copy license for use With this umareX proDuct, GranteD by hK, inc., u.s.a. 2279020 | Rev. 12/09 © 2009 mp7 a1 WarninG: not a toy. aDult supervision is reQuireD. misuse may cause serious injury, especially to the eye. eye protection DesigneD for airsoft guns must be worn by the user anD any person within range.
safe Gun hanDlinG Description operation care safety instructions 2 You should be fully familiar with the proper and safe handling of your airsoft gun. The basic principles of gun safety require you to always apply the following rules when handling an airsoft gun. • Always handle any gun as if it were loaded. • Always put the safety of the gun “ON SAFE” when loading it so that there can be no risk of an unintentional discharge.
Description caution you must be 18 years or older to purchase this airsoft gun. Carefully read and understand these instructions before using this airsoft gun. Buyers and users must follow the instructions for the safe use of airsoft guns. Front sight Magazine Release WarninG: never assume that because the airsoft gun no longer fires a bb anD/or the magazine is removeD from the grip frame that a plastic bb is not loDgeD in the barrel.
safety WarninG: you shoulD make it a habit to leave the safety always in the “on safe” position until you intenD to fire. caution • Only handle the airsoft gun when it is ON SAFE. • Always make sure that the muzzle points into a safe direction. charGinG of Gas DanGer: fire anD eXplosion haZarD contains flammable gas unDer pressure. will be easily igniteD by heat, sparks or flames. burning gas can make carbon monoXiDe (co). co (carbon monoXiDe) is invisible, has no smell, anD is lethal.
charGinG of Gas WarninG: keep hanDs anD face at a safe Distance from the escaping gas. escaping gas may cause icing. gas may eXploDe if eXposeD to temperatures eXceeDing 120°f. Do not smoke, keep away from open fire anD flames. the gas is highly inflammable. Turn the magazine upside down. Attach the gas flask vertically to the charging port of the magazine. Press the flask against the port. The magazine is fully charged when you observe a discharge of gas from the port.
loaD the maGaZine WarninG: use .24 caliber (6 mm) plastic bbs only in this airsoft gun. use of any other ammunition can cause injury to you or Damage to the airsoft gun. caution 1 Ø 6 mm 3 2 4 only use flawless high quality bbs. never use the following bbs: 1 diameter larger than 6mm, 2 with edges, 3 both halves not aligned, Warranty expires if non-recommended BBs are used. It’s recommended to use precision BBs from UMAREX. To ensure proper operation of the magazine, protect it from dirt and dust.
aDjustable siGhts shootinG WarninG: make sure that the muzzle of the gun always points into a safe Direction. never aim at pets or unsuspecting persons. always treat your gun as if it was loaDeD anD reaDy to fire. elevation adjustment Shoot too high: Shoot too low: 1. Before the first shot pull the charging handle. Windage adjustment Shoot too far right: Shoot too far left: 3. Pull trigger 2.
aDjustable hop up hanD Grip 1. 2. - hop up + hop up 2. Grip lock Button + hop up 1.
care anD maintenance perform routine inspections of the airsoft gun to check for proper operation. caution The exposed metal parts should be wiped clean using a slightly oiled cloth after handling to prevent rust. Use light acid free and resin free oil. RWS Spring Cylinder Oil is excellent for this. caution • Adjust the hop up to its normal position before cleaning the airsoft gun. • Do not force the rod into the barrel, as this could cause damage. • Never drip silicone oil directly into the barrel.
Warranty repair This product is warranted to the retail consumer for one (1) year from date of purchase against defects in material and workmanship and is not transferable. What is coVereD Replacement parts and labor. What is not coVereD Shipping charges to Umarex USA for defective product and damages caused by abuse or failure to perform normal maintenance as well as any other expense. Consequential damages, or incidental expenses, including damage to property.
370 fps 40 4.7 lbs. 23.5 in. We reserve the right to make color and design changes and technical improvements. No responsibility is accepeted for printing errors or incorrect information. Distributed by / Distribué par: www.umarexusa.com 6007 south 29th street fort smith, ar 72908 phone: 479-646-4210 Sauf modifications de la couleur et du design ainsi que des améliorations techniques, erreurs d‘impression et erreur. Toutes les données sont fournies sans garantie.
