Intended Use
This Ultra-Tow Trailer Winch with Universal A-Frame Mount is used to mount most standard winches
on A-frame trailers.
Technical Specifications
Property Specification
Material Steel
Capacity 1600 lb.
Strap with Hook 2 in. x 25 ft.
Dimensions 36 in. x 15 in. x 30 in.
Important Safety Information
⚠WARNING
Read and understand all instructions. Failure to follow all instructions may result in serious injury
or property damage.
The warnings, cautions, and instructions in this manual cannot cover all possible conditions or
situations that could occur. Exercise common sense and caution when using this winch. Always
be aware of the environment and ensure that the winch is used in a safe and responsible manner.
Do not allow persons to operate or assemble the product until they have read this manual and
have developed a thorough understanding of how it works.
Do not modify this winch in any way. Unauthorized modification may impair the function and/or
safety and could affect the life of the winch. There are specific applications for which the winch
was designed.
Use the right tool for the job. DO NOT attempt to force small equipment to do the work of larger
industrial equipment. There are certain applications for which this equipment was designed.
Products are safer and do a better job at the capacity for which they are intended. DO NOT use
this equipment for a purpose for which it was not intended.
Industrial or commercial applications must follow OSHA requirements.
⚠WARNING
This product may contain chemicals known to the State of California to cause cancer, birth defects or
other reproductive harm.
⚠WARNING
WORK AREA SAFETY
Inspect the work area before each use. Keep work area clean, dry, free of clutter, and well-lit.
Cluttered, wet, or dark work areas can result in injury. Using the winch in confined work areas
may put you dangerously close to cutting tools and rotating parts.
Keep children and bystanders away from the work area while operating the winch. Do not allow
children to handle the winch.
