Heavy-Duty Aluminum Arched Ramps 5000-Lb. Capacity Per Pair . Owner’s Manual WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. 12" x 60", 2,500 lbs.
Thank you very much for choosing an Ultra-Tow™ product! For future reference, please complete the owner’s record below: Serial Number/Lot Date Code: ________________________________ Purchase Date: ____________________________________________ Save the receipt, warranty, and this manual. It is important that you read the entire manual to become familiar with this product before you begin using it. This Heavy-Duty Aluminum Arched Ramp set is designed for certain applications only.
Table of Contents Intended Use .......................................................................................................................................... 4 Technical Specifications ...................................................................................................................... 4 Important Safety Information ............................................................................................................... 4 Specific Operation Warnings .......................
Intended Use Ultra-Tow’s Heavy-Duty Aluminum Arched Ramps are ideal for large ATV and Utility Vehicles. The arched design allows for extra clearance. Two safety straps are included with this ramp set. The ramps are ideal for large ATV & utility vehicles. Technical Specifications Property Rated Capacity Material Dimension Specification 5,000 lbs. per pair Aluminum 60 inches (L) x 12 inches (W) Important Safety Information ⚠WARNING Read and understand all instructions.
⚠WARNING PERSONAL SAFETY Stay alert, watch what you are doing, and use common sense when operating the ramp set. Do not use the ramp set while you are tired or under the influence of drugs, alcohol, or medication. A moment of inattention while operating the tool may result in serious personal injury. Dress properly. Do not wear loose clothing, dangling objects, or jewelry. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewelry, or long hair can be caught in moving parts.
Main Parts of 5000lbs Ramp Reference 1 Subassembly Aluminum Ramp Assembly Instructions Place the ramps directly into the groove of trailer. Make sure the ramps are stable and level. Maintenance Maintain ramp with care. Inspect ramp periodically, and if damaged have it repaired by an authorized technician. For your safety, maintenance should be performed regularly by a qualified technician. Clean the ramp after each use. Make sure any dirt, oil, grease, or debris are not present on the ramp.
Parts List Part No. 1 Item Description Aluminum Ramps Quantity 2 Replacement Parts For replacement parts and technical questions, please call Customer Service at 1-800-222-5381. Not all product components are available for replacement. The illustrations provided are a convenient reference to the location and position of parts in the assembly sequence.
Limited Warranty Northern Tool and Equipment Company, Inc. ("We'' or '"Us'') warrants to the original purchaser only ("You'' or “Your”) that the Ultra-Tow product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of one year from date of purchase. The foregoing warranty is valid only if the installation and use of the product is strictly in accordance with product instructions.
Distributed by: Northern Tool & Equipment Company, Inc. Burnsville, Minnesota 55306 www.northerntool.
