Heavy-Duty Trailer Dolly with Brake 1200-Lb. Capacity Owner’s Manual WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury.
® Thank you very much for choosing an Ultra-Tow product! For future reference, please complete the owner’s record below: Serial Number/Lot Date Code: ________________________________ Purchase Date: ____________________________________________ Save the receipt, warranty, and this manual. It is important that you read the entire manual to become familiar with this product before you begin using it. This dolly is designed for certain applications only.
Table of Contents Intended Use .......................................................................................................................................... 4 Technical Specifications ...................................................................................................................... 4 Important Safety Information ............................................................................................................... 4 Specific Operation Warnings .......................
Intended Use Ultra-Tow’s 1200 Lb. Capacity Heavy-Duty Trailer Dolly with Brake has a three-wheel design which makes maneuvering trailers easier than two-wheel models. The versatile design features flat-free tires and an adjustable height for many different trailer tongue heights. Technical Specifications Property Capacity Tires Construction Hitch Ball Size Adjustable Height Dimensions Specification 1200 lb.
Be aware of all power lines, electrical circuits, water pipes, and other mechanical hazards in your work area. Some of these hazards may be hidden from your view and may cause personal injury and/or property damage if contacted. ⚠WARNING PERSONAL SAFETY Stay alert, watch what you are doing, and use common sense when operating the tool. Do not use the tool while you are tired or under the influence of drugs, alcohol, or medication.
sudden tug or weight gain, which can result in damage to the product or personal injury. Always keep arms, feet and legs out from under the trailer tongue while hitching, unhitching or moving the trailer. Wear ANSI Z87.1 safety goggles during use. Always make sure the loaded trailer is chocked properly before moving the dolly into place. Maintain proper tire pressure at all times. DO NOT over inflate tire.
• Always check for damaged or worn parts before using the dolly. Replace or repair damaged or worn parts before using the dolly. Operating Instructions ⚠WARNING DO NOT exceed the rated load capacity. Distribute the load evenly. Uneven loads may cause the dolly to tip, resulting in personal injury to the operator or others. Always be aware of dynamic loading.
Maintenance Maintain the product by adopting a program of conscientious repair and maintenance in accordance with the following recommended procedures. It is recommended that the general condition of any tool be examined before it is used. Keep your tool in good repair. Keep handles dry, clean, and free from oil and grease. The following chart is based on a normal operation schedule. Maintenance Interval Daily before operating Maintenance Point Maintain your dolly.
Parts List Reference 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 Part Description Alex Assembly 16” Wheel Plate Washer Safety Pin Pin Shaft 2” Ball Mount Bracket 2” Trailer Hitch Ball Handle Tube Bolt M10x50 Lock Nut M10 Wheel Mounting Plate 10” Caster Bolt M10x25 Bolt M10x75 Bracket Handle Wire Brake Quantity 1 2 4 5 1 1 1 1 6 16 1 2 8 2 1 1 2 Replacement Parts For replacement parts and technical questions, please call Customer Service at 1-800-222-5381.
Limited Warranty Northern Tool and Equipment Company, Inc. ("We'' or "Us'') warrants to the original purchaser only ("You'' or "Your") that the Ultra-Tow product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of one year from date of purchase. The foregoing warranty is valid only if the installation and use of the product is strictly in accordance with product instructions.
