Intended Use
The 4.3 Inch Color Backup Camera is the perfect addition for any driver who needs assistance
backing up. It is an LCD monitor so it is very light, as well as thin. The license plate camera frame
included in this system will fit the license plate frame of any standard vehicle. The full-color lens on
the camera provides day time clarity and night vision with 120° viewable angles.
Packaging Contents
4.3 Inch Monitor
Backup Camera
65 foot Video Cable
Monitor Power Cable
DC Power Cable for
Camera
Owner’s Manual
Technical Specifications
Property
Specification
Power Source
9-12 Volt DC
Monitor Dimension (inch)
4.64 x 3 x 0.75
Viewing Angel
120 degree
Video Formats Available
PAL / NTSC
Digital Screen Resolution
480 x 272 Pixels
Night Vision Distance
20 Ft.
Operating Temperature
-20°C~+50°C , RH95％ MAX
Storage Temperature
-30°C ~+70°C RH95%
Important Safety Information
⚠WARNING
Read and understand all instructions. Failure to follow all instructions may result in serious injury
or property damage.
The warnings, cautions, and instructions in this manual cannot cover all possible conditions or
situations that could occur. Exercise common sense and caution when using this tool. Always be
aware of the environment and ensure that the tool is used in a safe and responsible manner.
Do not allow persons to operate or assemble the product until they have read this manual and
have developed a thorough understanding of how it works.
Do not modify this product in any way. Unauthorized modification may impair the function and/or
safety and could affect the life of the product. There are specific applications for which the product
was designed.
Use the right tool for the job. DO NOT attempt to force small equipment to do the work of larger
industrial equipment. There are certain applications for which this equipment was designed. This
product will be safer and do a better job at the capacity for which it was intended. DO NOT use
this equipment for a purpose for which it was not intended.
Industrial or commercial applications must follow OSHA requirements.
