4.3In. Color Backup Camera Owner’s Manual WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury.
Thank you very much for choosing an Ultra-Tow™ product! For future reference, please complete the owner’s record below: Serial Number/Lot Date Code: ________________________________ Purchase Date: ____________________________________________ Save the receipt, warranty, and this manual. It is important that you read the entire manual to become familiar with this product before you begin using it. This camera is designed for certain applications only.
Table of Contents Intended Use .......................................................................................................................................... 4 Packaging Contents .............................................................................................................................. 4 Technical Specifications ...................................................................................................................... 4 Important Safety Information .................
Intended Use The 4.3 Inch Color Backup Camera is the perfect addition for any driver who needs assistance backing up. It is an LCD monitor so it is very light, as well as thin. The license plate camera frame included in this system will fit the license plate frame of any standard vehicle. The full-color lens on the camera provides day time clarity and night vision with 120° viewable angles. Packaging Contents 4.
⚠WARNING WORK AREA SAFETY Inspect the work area before each use. Keep work area clean, dry, free of clutter, and well-lit. Cluttered, wet, or dark work areas can result in injury. Using the product in confined work areas may put you dangerously close to cutting tools and rotating parts. Do not use the product where there is a risk of causing a fire or an explosion; e.g., in the presence of flammable liquids, gases, or dust.
before using. Disconnect the power/air supply from the product and place the switch in the locked or off position before making any adjustments, changing accessories, or storing the tool. Such preventive safety measures reduce the risk of starting the tool accidentally. Store the camera when it is not in use. Store it in a dry, secure place out of the reach of children. Inspect the tool for good working condition prior to storage and before re-use.
Assembly Instructions ⚠WARNING The monitor contains high voltage. The cover should be opened by qualified technicians only. 1. Connect the monitor wires (Figure 1). a. Connect one side of the 20m cable with the yellow connector (#1) or white connector (#2) on the monitor wire. b. Connect the red connector (#3) to the 1.5m power cable. c. Connect the red wire (#4) to the reversing light power positive. Use the black wire (#5) for grounding. Wires #4 and #5 are on the other end of the 1.
b. Connect the wire with the red connector (#7) to the 1.5m cable. c. Connect the red wire (#8) to the reversing light power positive. Use the black wire (#9) for grounding. Wires #8 and #9 are on the other end of the 1.5m cable (opposite of #7). Figure 2 Figure 3 shows the entire wire connection. Figure 3 BACK-UP CAMERA INSTALLATION 1. The camera is designed to be mounted with the fasteners of most license plate holders.
that the camera’s field of vision is free of obstructions (bumpers, hitches, etc.).The camera should be positioned as close to the center of the vehicle as possible. 2. Secure the camera to the vehicle. The back-up camera is designed to be mounted to the license plate frame using mounting hardware (NOT INCLUDED). 3. Locate the vehicle’s reverse light wire. This can easily be found at the reverse light bulb or at the trailer harness if your car is equipped with one. Test this wire with a multi-meter.
After Each Use ⚠WARNING To avoid property damage, do not expose the monitor to excessive heat or cold. The storage temperature of the camera is -30 to +70°C and the operating temperature is -20 to +50°C. The humidity is Rh90%. Maintenance ⚠WARNING Remove all the cable connections from the monitor before cleaning the unit. Use a mild household detergent and clean the unit with a slightly damp, soft cloth.
Limited Warranty Northern Tool and Equipment Company, Inc. ("We'' or "Us'') warrants to the original purchaser only ("You'' or "Your") that the Ultra-Tow product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of three years from date of purchase. The foregoing warranty is valid only if the installation and use of the product is strictly in accordance with product instructions.
Distributed by: Northern Tool & Equipment Company, Inc. Burnsville, Minnesota 55306 www.northerntool.
