iXon Ultra
Troubleshooting
To map each port, use a High Bandwidth device such as a modern USB memory stick. High bandwidth devices will only
appear in an EHC section, as shown below, where one can see the USB mass storage device under “Enhanced Host
Controller - 3A6A”. There is a second EHC called 3A6C. Test each physical port by placing the USB memory stick into it
and record which EHC it is connected to. After changing the port the window should update automatically after several
seconds – if it does not, press F5 to refresh it.
Example USB Map Hub and layout
First EHC 3A6C
Second EHC 3A6A
Front:
3A6A
3A6A 3A6C
3A6C
3A6A
3A6A 3A6C
3A6C
Back:
