iXon Ultra
, Features and Functionality
Andor recommends using the default highest value pre-amp setting (e.g. Gain3 setting of the iXon Ultra 897E giving
~ 4 e-/count @ 10MHz) for most low-light applications. Most genuinely low-light applications are not limited by well
capacity, as long as sensible EM Gain settings are applied (we recommend not exceeding x500 EM Gain, except for
single photon counting experiments). Even at this highest pre-amp setting, the typical imaging pixel well depth will still
be exceeded before the 16-bit A/D would saturate (180,000 e- ÷ 4 e-/count = 45,000 e-). The remainder of the 16-bit
A/D range is therefore still free to be utilized by the extended well capacity of the gain register. For example, with an EM
Gain of x300 (RealGain
TM
), it would take 600 electrons in a pixel of the sensor to reach this A/D saturation limit. Say the
QE is 80% at the wavelength of interest then this corresponds to maximum of 750 photons falling onto that pixel. That is
perfectly satisfactory dynamic range for the vast majority of low-light imaging applications.
NOTE: A Side effect of the new high speed ADC method chosen for the iXon Ultra, is that the full range of ADC
codes 0- 65535 is not available. A margin has been added and the iXon will reach an ADC saturation that is lower
than 65535. See Camera performance sheet for details.
The core reason for recommendation of this pre-amp setting, even over the middle (Gain2) pre-amp setting, is that it
implements an additional restriction as to how much charge is allowed to build up in the sensor. This in turn will help
minimize the rate of EM Gain ageing (please see page 42 for further details on measures against gain ageing). However,
some applications can be very demanding of dynamic range, and for those a lower pre-amp setting such as Gain2 is
recommended. This ensures the A/D capacity is more closely matched to the well capacity of the gain register pixels and
provides the maximum dynamic range. Also, as mentioned above, to maximize the true dynamic range of the camera
tuning the RealGain
TM
gain setting to a value close to the value of the readout noise at the selected readout speed is
recommended (e.g. if readout noise is ~ 50 electrons @ 10 MHz, set the EM Gain to x50 for maximum dynamic range).
