Version 1.1 rev Jan 2013
Page 41
iXon Ultra
, Features and Functionality
S/N plots derived from the specications of the back-illuminated iXon Ultra EMCCDs at 1MHz (slower frame rate
operation) read out either with EM Gain ON or, alternatively, through the conventional amplier (i.e. standard CCD
operation) are shown in Figure 10. Again, this plot assumes a photon wavelength at which the QE of the sensor is 90%.
This gure applies specically to models where the user has the choice of either EMCCD or conventional ampliers.
At these slower speed operations, when one has the choice to read out as a “conventional” CCD, it can often be
advantageous to do so in order to achieve improved signal to noise. The plots below show that the cross-over point is at
~42 photons/pixel, at which it is still advisable to read out through the EM amplier with Gain applied.
Figure 10: EM Gain ON vs. Conventional Amplier signal to noise plots for back-illuminated iXon Ultra EMCCDs at 1MHz readout speed
