Version 1.1 rev Jan 2013
Page 12
iXon Ultra
SAFETY AND WARNINGS INFORMATION
Safety and Warnings Information
PLEASE READ THIS INFORMATION FIRST
1. To ensure correct and safe operation of this product, please read this guide before use and keep it in a safe place
for future reference.
2. If the equipment is used in a manner not specied by Andor, the protection provided by the equipment may be
impaired.
3. Before using the system, please follow and adhere to all warnings, safety, manual handling and operating
instructions located either on the product or in this User Guide.
4. The Andor iXon Ultra camera is a precision scientic instrument containing fragile components. Always handle with
care.
5. Do not expose the product to extreme hot or cold temperatures.
6. Ensure that the ventilation slots in the camera case are free from blockages.
7. Do not expose the product to open ames.
8. Do not allow objects to fall on the product.
9. Do not expose the product to moisture, wet, or spill liquids on the product. Do not store or place liquids on the
product. If spillage occurs on the product, switch off power immediately and wipe off with dry, lint-free cloth. If any
ingress has occurred or is suspected, unplug mains cable, do not use, and contact Andor service.
10. The product contains components that are extremely sensitive to static electricity and radiated electromagnetic
elds, and therefore should not be used, or stored, close to EMI/RFI generators, electrostatic eld generators,
electromagnetic or radioactive devices, or other similar sources of high energy elds.
11. Operation of the system close to intense pulsed sources (e.g. plasma sources, arc welders, radio frequency
generators, X-ray instruments, and pulsed discharge optical sources) may compromise performance if shielding of
the Camera is inadequate.
12. Use only the power supply cord provided with the system for this unit. Should this not be correct for your
geographical area contact your local Andor representative.
13. Only the correctly specied mains supply must be used.
14. Make sure the electrical cord is located so that it will not be subject to damage.
15. There are no user-serviceable parts in the camera. Only authorised service personnel may service this equipment .
16. Users must be authorised and trained personnel only; otherwise this may result in personal injury, and/or equipment
damage and impaired system performance.
