User's Manual

SR71-A
Outdoor 3x3 802.11n MIMO mini-PCI Module
www.ubnt.com
DataRate Avg. TX Tolerance DataRate Sensitivity Tolerance
1-24Mbps 24 dBm +/-2dB 1-24Mbps -97 dBm +/-3dB
36Mbps 22 dBm +/-2dB 36Mbps -90 dBm +/-3dB
48Mbps 20 dBm +/-2dB 48Mbps -86 dBm +/-3dB
54Mbps 19 dBm +/-2dB 54Mbps -84 dBm +/-3dB
MCS0 24 dBm +/-2dB MCS0 -97 dBm +/-3dB
MCS1 24 dBm +/-2dB MCS1 -96 dBm +/-3dB
MCS2 24 dBm +/-2dB MCS2 -93 dBm +/-3dB
MCS3 22 dBm +/-2dB MCS3 -91 dBm +/-3dB
MCS4 22 dBm +/-2dB MCS4 -87 dBm +/-3dB
MCS5 22 dBm +/-2dB MCS5 -84 dBm +/-3dB
MCS6 18 dBm +/-2dB MCS6 -78 dBm +/-3dB
MCS7 15 dBm +/-2dB MCS7 -75 dBm +/-3dB
MCS8 24 dBm +/-2dB MCS8 -96 dBm +/-3dB
MCS9 24 dBm +/-2dB MCS9 -94 dBm +/-3dB
MCS10 22 dBm +/-2dB MCS10 -91 dBm +/-3dB
MCS11 20 dBm +/-2dB MCS11 -88 dBm +/-3dB
MCS12 20 dBm +/-2dB MCS12 -85 dBm +/-3dB
MCS13 17 dBm +/-2dB MCS13 -80 dBm +/-3dB
MCS14 17 dBm +/-2dB MCS14 -79 dBm +/-3dB
MCS15 15 dBm +/-2dB MCS15 -76 dBm +/-3dB
DataRate Avg. TX Tolerance DataRate Sensitivity Tolerance
1-24Mbps 24 dBm +/-2dB 1-24Mbps -96 dBm +/-3dB
36Mbps 22 dBm +/-2dB 36Mbps -95 dBm +/-3dB
48Mbps 20 dBm +/-2dB 48Mbps -94 dBm +/-3dB
54Mbps 19 dBm +/-2dB 54Mbps -91 dBm +/-3dB
MCS0 24 dBm +/-2dB MCS0 -96 dBm +/-3dB
MCS1 24 dBm +/-2dB MCS1 -95 dBm +/-3dB
MCS2 24 dBm +/-2dB MCS2 -92 dBm +/-3dB
MCS3 22 dBm +/-2dB MCS3 -90 dBm +/-3dB
MCS4 22 dBm +/-2dB MCS4 -86 dBm +/-3dB
MCS5 22 dBm +/-2dB MCS5 -83 dBm +/-3dB
MCS6 18 dBm +/-2dB MCS6 -77 dBm +/-3dB
MCS7 15 dBm +/-2dB MCS7 -74 dBm +/-3dB
MCS8 24 dBm +/-2dB MCS8 -95 dBm +/-3dB
MCS9 24 dBm +/-2dB MCS9 -93 dBm +/-3dB
MCS10 22 dBm +/-2dB MCS10 -90 dBm +/-3dB
MCS11 20 dBm +/-2dB MCS11 -87 dBm +/-3dB
MCS12 20 dBm +/-2dB MCS12 -84 dBm +/-3dB
MCS13 17 dBm +/-2dB MCS13 -79 dBm +/-3dB
MCS14 17 dBm +/-2dB MCS14 -78 dBm +/-3dB
MCS15 15 dBm +/-2dB MCS15 -75 dBm +/-3dB
MODE 6Mbps MCS0 MCS15 MODE 6Mbps MCS0 MCS15
100% TX 1.25A 1.25A 1.25A 100% TX 1.25A 1.25A 1.25A
Real-World 0.75A 0.80A 0.45A Real-World 0.75A 0.80A 0.35A
Idle 0.30A 0.30A 0.30A Idle 0.30A 0.30A 0.30A
RoHS Compliance
-20C to +70C (extended temp version up to +95C)
802.11i with AES-CCM & TKIP Encryption, 802.1x, 64/128/152bit WEP
Legacy 802.11a/b/g (1-54Mbps), 802.11n (up to 300Mbps)
Data Rates
Security
Temperature Range
YES
Radio Operation
Wireless Chipset
IEEE 802.11a/b/g/n
Atheros AR9160 with DFS SUPPORT
Operation Voltage
Interface
3.3VDC
(3) MMCX for 3x3 MIMO Operation
32-bit mini-PCI Type IIIA
Antenna Ports
OPERATING FREQUENCY 2412MHz-2462MHz
greater than 60km
Wireless Modular Approvals
FCC , Industry Canada, CE (100mW limited)
2.4GHz RX SPECIFICATIONS
REGULATORY INFORMATION
11b/g
Ubiquiti LiteStationX + AirOS
11b/g
Outdoor (Antenna Dependent):
Indoor (Antenna Dependent):
OPERATING FREQUENCY 5745MHz-5825MHz
AVG. CURRENT CONSUMPTION INFORMATION
greater than 300m
RANGE PERFORMANCE
DRIVER INFORMATION
For help with special driver support, please e-mail [e-mail]
2.4GHz 11n HT20 / HT40
Operating System Support
2.4GHz 11n HT20 / HT40
2.4GHz TX POWER SPECIFICATIONS
5GHz RX SPECIFICATIONS
11a
11a
5GHz TX POWER SPECIFICATIONS
5GHz 11n
5GHz 11n
