User's Manual



FortheMasterandSlave,ensuretheAzimuth(AZ)andElevation(EL)AdjustmentBoltsareinthemiddleoftheiradjustmentranges.

Master
 AimtheMasterattheSlave.Ifnecessary,adjusttheMaster'spositiononthepole:
LoosentheHexNuts.
AdjustthePoleMountBracketandPoleClamps.
TightentheHexNuts.

Slave
 AimtheSlaveattheMastertoachievethestrongestreceivedsignallevelontheSlave'snumericLEDDisplay,whichislocatednexttothe
MANAGEMENTport.Ifnecessary,adjusttheSlave'spositiononthepole.

 Note:ValuesontheLEDDisplayaredisplayedin
negative(‐)dBm.Forexample,61representsareceived
signallevelof‐61dBm.Lowervaluesindicatestronger
receivedsignallevels.

Master
 AdjusttheazimuthandelevationoftheMasteruntilthestrongestreceivedsignallevelisdisplayedontheLEDDisplayoftheMaster.
SweeptheAzimuth(AZ)AdjustmentBoltoftheMasterthroughitsadjustmentrange.
SweeptheElevation(EL)AdjustmentBoltoftheMasterthroughitsadjustmentrange.

 Note:IftheLEDDisplayindicatesanoverloadcondition,
refertotheairFiberAF5UUserGuideat:
documentation.ubnt.comformoreinformation.

Fine‐TuningtheLink
TheAzimuth(AZ)andElevation(EL)AdjustmentBoltsoftheAlignmentBracketadjusttheazimuthandelevationwithinarangeof±10°.For
accuratealignment,makeadjustmentsononeendofthelinkwhiletheotherinstallerreportsthereceivedsignallevelattheotherendofthe
link.DoNOTmakesimultaneousadjustmentsonthe
MasterandSlave.
Slave
 AdjusttheazimuthandelevationoftheSlaveuntiltheotherinstallerseesthestrongestreceivedsignalleveldisplayedontheLED
DisplayoftheMaster.
Master
 AdjusttheazimuthandelevationoftheMasteruntiltheotherinstallerseesthestrongestreceivedsignalleveldisplayedontheLED
DisplayoftheSlave.
Repeatsteps1and2untilyouachieveasymmetriclink,withthereceivedsignallevelswithin1dBofeachother.Thisensuresthebest
possibledataratebetweentheairFiberradios.
LockthealignmentonbothairFiberradiosbytighteningalleightLockBoltsontheAlignmentBracket.
ObservetheLEDDisplayofeachairFiberAF5UtoensurethatthevalueremainsconstantwhiletighteningtheLockBolts.IftheLEDvalue
changesduringthelockingprocess,loosentheLockBolts,finalizethealignmentofeachairFiberAF5Uagain,andretightentheLockBolts.
ForeachairFiberAF5U,attachthePortCoverandturntheCoverLocktotheLockedicon.

Therearethreemethodsfordeterminingthereceivedsignallevel:
LEDDisplay(describedabove)
airFiberConfigurationInterface
Audiotone(optionalequipmentrequired)
RefertotheairFiberAF5UUserGuideforinstructionsontheairFiberConfigurationInterfaceandaudiotonemethods.TheUserGuideis
availableat:documentation.ubnt.com

