UVP-Executive Specications
UVP-Executive
Dimensions 254.6 x 135 x 182.5 mm (10.02 x 5.31 x 7.19")
Weight 1.52 kg (3.35 lbs)
Display 7" (Diagonal), 1024 x 600, 170 ppi, Multi-Touch, Full Color
Camera 1.0 MP (HD720p)
LED Power: White, Glowing
Handset
Dynamic Receiver 32 ohm/101 dB/30mW
Microphone Omnidirectional/-36dB/2.2Kohm
Echo Cancellation DSP Removing Ambient Noise and Acoustic Echo
Power Input PoE 802.3.at (26W)
Hands-Free Speaker Stereo 4.0W
Hands-Free Microphone Omnidirectional/SNR 61 ± 5 dB/Sensitivity -38 ± 3dB Analog Silicon Microphone
Connectivity (2) 10/100/1000 Ethernet Ports
(1) USB 2.0 microUSB Port
(1) USB 2.0 Type A USB Host Port
Bluetooth 4.0
Wi-Fi 802.11 a/b/g/n
Headset Support 3.5 mm Audio Jack
270mW CTIA (LRGM)
Accessory Detection Volume Up/Down and Media Detection
Processor Dual-Core Cortex A9, 1.2 GHz
Storage 4 GB (Shared with Other Applications)
RAM 1 GB
Software
OS Android Kit Kat (Version 4.4.2)
Voice Codec G.722/Speex/iLBC/PCMU/PCMA/GSM
Communication Software UniFi Phone App
Management Features Auto-Provisioning
Protocol SIP/SDP/RTP/RTCP/VLAN/DHCP
