Datasheet Enterprise VoIP Phone with Touchscreen Models: UVP, UVP-Pro, UVP-Executive High-Definition, Multi-Touch Color Display Powered by Android™ Integrates with UniFi® Enterprise System
Datasheet Smartphone Technology for Corporate Environments The UniFi VoIP Phone is an enterprise desktop smartphone solution with a brilliant, high-definition color display designed for modern communication, organization, and productivity. Built on Android and integrated into Ubiquiti’s UniFi Enterprise System, the UniFi VoIP Phone is the next‑generation standard for corporate communications.
Datasheet Model: UVP The UniFi VoIP Phone is the base model in the UniFi VoIP family. Designed to easily integrate into a UniFi network, the UniFi VoIP Phone includes the following features: • 5-Inch*, High-Definition, Multi-Touch Color Display • Powered by Android • High-Fidelity Audio Model: UVP-Pro The UniFi Pro VoIP Phone provides the same great set of features included with the base model and also offers a built-in camera and Wi-Fi functionality.
Datasheet UVP Specifications UVP Dimensions 166 x 140 x 182.5 mm (6.50 x 5.50 x 7.19") Weight 1.10 kg (2.43 lbs) Display 5" (Diagonal), 640 x 960, 231 ppi, Multi-Touch, Full Color LED Power: White, Glowing Dynamic Receiver 32 ohm/101 dB/30mW Microphone Omni‑Directional/-36 dB/2.2K ohm Handset Echo Cancellation DSP Removing Ambient Noise and Acoustic Echo Power Input PoE 802.3.af (13W) Hands-Free Speaker Hands-Free Microphone Mono 2.
UVP-Pro Dimensions 166 x 140 x 182.5 mm (6.50 x 5.50 x 7.19") Weight 1.10 kg (2.43 lbs) Display 5" (Diagonal), 640 x 960, 231 ppi, Multi-Touch, Full Color Camera 1.0 MP (HD720p) LED Power: White, Glowing Dynamic Receiver 32 ohm/101 dB/30mW Microphone Omnidirectional/-36 dB/2.2K ohm Handset Echo Cancellation DSP Removing Ambient Noise and Acoustic Echo Power Input PoE 802.3.at (26W) Hands-Free Speaker Hands-Free Microphone Datasheet UVP-Pro Specifications Mono 2.
Datasheet UVP-Executive Specifications UVP-Executive Dimensions 254.6 x 135 x 182.5 mm (10.02 x 5.31 x 7.19") Weight 1.52 kg (3.35 lbs) Display 7" (Diagonal), 1024 x 600, 170 ppi, Multi-Touch, Full Color Camera 1.0 MP (HD720p) LED Power: White, Glowing Dynamic Receiver 32 ohm/101 dB/30mW Microphone Omnidirectional/-36 dB/2.2K ohm Handset Echo Cancellation DSP Removing Ambient Noise and Acoustic Echo Power Input PoE 802.3.at (26W) Hands-Free Speaker Hands-Free Microphone Stereo 4.
