Specifications & Dimensions

PERFORMANCE

• Uses less than 3 gallons of water to produce up to 25 lbs of ice

per day

• Up to 25 lbs in ice storage capacity

• Daily ice production rate is approx. 4 times greater than the

average household refrigerator

• Crescent ice cube dimensions: 1⁄2” W x 3⁄4” H x 2 1⁄4” L

• On/Oﬀ switch is conveniently located on lower face of unit

INTERIOR/EXTERIOR

• No drain required

• Standard commercial stainless steel handle is interchangeable

with professional handle accessory

• Door swing is ﬁ eld reversible, and is shipped right-hand hinged

INTEGRATION

• Unit is designed to be built-in or can be freestanding

• Integrated model requires 3⁄4” custom door panel (panels not

supplied by U-Line)

• Four independently adjustable leveling legs provide a precise

undercounter ﬁ t

• Available in the following ﬁ nishes: Stainless, Integrated, Black,

or White

BLACK

SOLID

STAINLESS

SOLID

INTEGRATED

SOLID

WHITE

SOLID

MODEL DETAILS

Model Voltage/Hz Door Swing Finish Shipping Weight

U-BI1215S-00B 115 / 60 Field Reversible Stainless Solid 89 lb

U-BI1215INT-00B 115 / 60 Field Reversible Integrated Solid 89 lb

U-BI1215B-00B 115 / 60 Field Reversible Black Solid 89 lb

U-BI1215W-00B 115 / 60 Field Reversible White Solid 89 lb

ACCESSORIES

Model Description Finish Shipping Weight

80-54247-00 Professional Door Handle, 1 1⁄4” Diameter Stainless

2 lb

80-54674-00 Braided water supply line kit N/A 2 lb

BI1215 • 15” Crescent Ice Maker • 1000 Series

PRODUCT SPECIFICATIONS

FEATURES & BENEFITS

PAGE 1
PRODUCT SPECIFICATIONS BI1215 • 15” Crescent Ice Maker • 1000 Series INTERIOR/EXTERIOR PERFORMANCE FEATURES & BENEFITS BLACK SOLID • • • • • • • Uses less than 3 gallons of water to produce up to 25 lbs of ice per day Up to 25 lbs in ice storage capacity Daily ice production rate is approx.
PAGE 2
PRODUCT SPECIFICATIONS 1000 Series • 15” Crescent Ice Maker • BI1215 DIMENSIONS SPECIFICATIONS Dimensions shown apply to all finishes, including Integrated (INT) models with 3⁄4” integrated panel/frame installed. Not Including Handle 23-1/4" (591 mm) 34-1/8" to 35-1/8" (867 mm to 892 mm) 3-9/16" (91 mm) 14-15/16" (379 mm) CABINET CUT-OUT Preferred location for water line and eletrical outlet is in adjacent cabinet. 34-1/4" (870 mm) to 35" (889 mm) Model BI1215 Amps: Running 2.
