Specification Sheet

ManualsBrandsU-Line ManualsDomestic AppliancesU-3036WCWCS-13B

STAINLESS

FRAME

INTEGRATED

SOLID

STAINLESS FRAME

(LOCK)

INTEGRATED

FRAME (STAINLESS

HANDLELESS PANEL)*

INTEGRATED

SOLID (STAINLESS

HANDLELESS PANEL)*

INTEGRATED

FRAME

PERFORMANCE

• Volume of 7.0 cu ft holds up to 62 wine bottles (750 ml)

• U-Select

Control with digital OLED display

• Temperature range: 38°F - 65°F

• Convection cooling system rapidly and eﬃ ciently takes items to

the set temperature

• U-Select

Control has three distinct modes:

Sparkling Wine: 38°F - 50°F, White Wine: 45°F - 55°F,

Red Wine: 55°F - 65°F

• Independently controlled dual-zones

• Rubber mounted compressor virtually eliminates vibration

• Exceeds 2019 energy standard by 45% (Tested according to 2019

Department of Energy - standard 10 C.F.R. section 430.23)

INTERIOR/EXTERIOR

• Black interior is illuminated with LED theater lighting that

automatically turns oﬀ when the door is closed, or can be set to

stay on for 3, 6, or 24 hours

• Full extension black coated wine racks allow for easy access and

prevent bottles from shifting

• Wine racks accommodate a variety of bottle shapes and sizes;

the fourth and ﬁ fth racks allow for larger diameter wine and

champagne bottles

• LowE coated, argon gas ﬁ lled triple thermopane glass door

provides protection from harmful UV light

• Standard commercial stainless steel handle are interchangeable

with professional handle accessory

• Door lock model available

INTEGRATION

• Robust, concealed and covered hinges with built-in door stop and

closer

• Adjustable grille can be shifted front-to-back and up-and-down

• Integrated model requires 3⁄4” custom panel of your choice, or can

accept U-Line Euro Style Handleless Stainless Panel Accessory

(must be ordered separately)

• Grille can accept an integrated toe-kick

• Four independently adjustable leveling legs

MODEL DETAILS

Model Voltage/Hz Door Swing Finish Shipping Weight

U-3036WCWCS-00B 115 / 60 Double Doors Stainless Frame 252 lb

U-3036W

CWCS-13B 115 / 60 Double Doors Stainless Frame (Lock) 252 lb

U-3036WCWCINT-00B 115 / 60 Double Doors Integrated Frame 235 lb

U-3036WCWCINT-60B 115 / 60 Double Doors Integrated Solid 234 lb

ACCESSORIES

Model Description Finish Shipping Weight

80-54247-00 Professional Door Handle, 1 1⁄4” Diameter (single handle)

Stainless

2 lb

U-ESPF45S* Euro Style Handleless Panel, 18” Frame (single panel) Stainless

6 lb

U-ESP45S* Euro Style Handleless Panel, 18” Solid (single panel) Stainless

9 lb

*Installs on integrated models, 2 panels required.

3036WCWC • 36” Wine Captain

Model • Modular 3000 Series

PRODUCT SPECIFICATIONS

FEATURES & BENEFITS

Summary of content (2 pages)

PAGE 1
PRODUCT SPECIFICATIONS 3036WCWC • 36” Wine Captain® Model • Modular 3000 Series PERFORMANCE FEATURES & BENEFITS • • • • • • • • STAINLESS FRAME STAINLESS FRAME (LOCK) INTEGRATED FRAME (STAINLESS HANDLELESS PANEL)* INTERIOR/EXTERIOR • • • • • • INTEGRATED FRAME INTEGRATED SOLID INTEGRATED SOLID (STAINLESS HANDLELESS PANEL)* INTEGRATION • • • • • Volume of 7.
PAGE 2
PRODUCT SPECIFICATIONS Modular 3000 Series • 36” Wine Captain® Model • 3036WCWC DIMENSIONS SPECIFICATIONS Dimensions shown apply to all finishes, including Integrated (INT) models with 3⁄4” integrated panel/frame installed. Not Including Handle 23-7/16" (590 mm) 33-11/16" to 34-11/16" (856 to 881 mm) 35-7/16" (900 mm) 3-5/8" to 4-5/8" (92 to 118 mm) CABINET CUT-OUT Preferred location for electrical outlet is in adjacent cabinet.
