Specification Sheet

35-7/16"
(900 mm)
33-11/16" to 34-11/16"
(856 to 881 mm)
23-7/16" (590 mm)
3-5/8" to
4-5/8"
(92 to
118 mm)
Not Including Handle
4"
(102 mm)
7"
(178 mm)
33-7/8"
(860 mm)
to
34-7/8"
(886 mm)
Preferred location
for electrical outlet
is in adjacent
cabinet.
5/8"
(16 mm)
24"
(610 mm)
Metric measurements rounded and optimized.
35-5/8"
(905 mm)
Model 3036RRGL
Amps: Running 1.2
Capacity: Bottle (12 oz) 158
Capacity: Can (12 oz) 246
Capacity: Volume (cu ft) 6.9
Control Type U-Select
®
Dimensions: Product Depth 23 7⁄16" / 590 mm
Dimensions: Product Height 33 11⁄16" / 856 mm
Dimensions: Product Width 35 7⁄16" / 900 mm
Energy Consumption: Avg. Per Year 320 kWh
ENERGY STAR No
Panel Height 30" / 762 mm
Panel Thickness 3⁄4" / 20 mm
Panel Type 2 3⁄4" / 70 mm Frame Panel
Panel Width 17 5⁄8” / 445 mm
Product Weight: Max 203 lb
Refrigerant Type R600a
Sabbath (Star K Certifi ed) Yes
Temperature Range 34°F - 70°F
When installing adjacent to wall, ensure 2 1⁄2”
clearance on hinged side for 90˚ door opening,
allowing ample room for door handle.
No additional clearance around sides, top or rear of
unit is needed for ventilation.
Do not obstruct front grille air fl ow.
This unit requires a grounded, polarized 115 VAC, 60 Hz, 15 A power
supply (normal household current).
34°-70° 34°-70°
COOLING SYSTEM
Warranty
plus
eligible
1
Modular 3000 Series • 36” Glass Door Refrigerator • 3036RRGL
8900 North 55th Street • Milwaukee, Wisconsin 53223 USA • Phone [phone] • Fax [phone] • u-line.com
PRODUCT SPECIFICATIONS
DIMENSIONS SPECIFICATIONS
ELECTRICAL REQUIREMENTS
CABINET CUT-OUT
Please visit u-line.com to view this model’s User Guide & Service
Manual. All Specifi cations are subject to change without notice.
INSTALLATION NOTES
Dimensions shown apply to all fi nishes, including Integrated
(INT) models with 3⁄4” integrated panel/frame installed.
