quick start_guide

QUICK START GUIDE
11
u-line.com
(6.4 mm to 12.7 mm) in depth. A fuller cube with less of a
dimple results in a thicker ice bridge. As the ice bridge
thickens, the tendency for the cubes to stay together as a
slab increases. A bridge thicker than 1/8" (3.2 mm) may
cause cubes to overfill the ice bucket.
32 ice cubes are formed on a 4 x 8 slab during each cycle.
Each cycle takes approximately 15-20 minutes at the
default cube thickness (0).
Your clear ice machine is pre-set to produce ice between
the optimal dimensions illustrated below:
DIMPLES
ICE BRIDGE
7/8"
(22 mm)
7/8"
(22 mm)
1/4" TO 1/2"
(6.4 mm to 12.7 mm)
DIMPLE
1/16" TO 1/8"
(1.6 mm to 3.2 mm)
ICE BRIDGE
Cube Details
Factory Default Setting - 0
THINNER BRIDGE
THICKER BRIDGE
DEEPER DIMPLE
SHALLOWER DIMPLE
ULIN_0300_A
< 0
SETTING
> 0
SETTING
ICE ADJUST
Adjust ice thickness as follows:
1. Press and hold for 5 seconds to enter the
Customer Menu.
2. Press
to select “Ice Adjust”.
3. Press . The selection will begin to flash.
4. Press to make the ice thicker or to make the ice
thinner.
Press to confirm your choice.
Up
Select
Down
RETURN TO MENU
ICE ADJUST
ICE ADJUST = 0
and
