TRANSTIG 170Pi
Manual 0-5241 2-5 INTRODUCTION
2.10 Specifications
Description Transtig 170Pi
Plant Part No
Power Source Part No
W1007190
W1007189
Power Source Dimensions H324mmxW122mmxD458mm
Power Source Mass 11.5 KG
Cooling Fan Cooled
Welder Type Multi Process Inverter Power Source
Australian Standard AS 60974.1-2006 / IEC 60974.1
Number of Phases Single Phase
Nominal Supply Voltage 240V ± 15%
Nominal Supply Frequency 50/60Hz
Welding Current Range 5-170A
Nominal DC Open Circuit Voltage (VRD ON) 8V
Nominal DC Open Circuit Voltage (VRD OFF) 66V
Factory Fitted Supply Plug Rating 15 Amps
Effective Input Current (I
1eff ) refer Note 2 13 Amps
Maximum Input Current (I
1max) 23.5 Amps
Minimum Single Phase Generator
Recommendation (refer Note 4)
6.6k W (8.5k VA at 0.8 PF)
STICK (MMAW) Welding Output, 40ºC, 10 min. 170A @ 30%, 26.8V
130A @ 60%, 25.2V
100A @ 100%, 24.0V
TIG (GTAW) Welding Output, 40ºC, 10 min. 170A @ 30%, 16.8V
130A @ 60%, 15.2V
100A @ 100%, 14.0V
Protection Class IP23S
Table 2-1: Transtig 170Pi Specifications
NOTE 1
Due to variations that can occur in manufactured products, claimed performance, voltages, ratings,
all capacities, measurements, dimensions and weights quoted are approximate only. Achievable
capacities and ratings in use and operation will depend upon correct installation, use, applications,
maintenance and service.
NOTE 2
The Effective Input Current should be used for the determination of cable size & supply requirements.
NOTE 3
Motor start fuses or thermal circuit breakers are recommended for this application. Check local
requirements for your situation in this regard.
