User guide

ARCMASTER

160 S

March 31, 2006 13-1

SECTION 13:

OPTIONS AND ACCESSORIES

PRODUCT PART NO. DESCRIPTION

Carry Case 600304 Accommodates the power supply, regulator, stick work lead, TIG torch &

accessory kit

Stick Kit 90924A Work clamp with 15’ #4 cable, and stick electrode with 15’ #4 cable

TIG Kit 600288 Includes regulator/ﬂ owgauge, 12.5ft 150 Amp TIG torch with valve,

accessory kit includes 1 ea of 0040”x7”, 1/16”x7”, 3/32”x7” 2% Tungsten

with collet & collet bodies, 1 ea 1/4”, 5/16”, 3/8” alumina cup, 15’ cable

with clamp & T25 dinse plug

W4009101 Includes regulator/ﬂ owgauge, 12.5ft 150 Amp TIG torch with valve and rotary

amperage control, accessory kit includes 1 ea of 0.040”x7”, 1/16”x7”,

3/32”x7” 2% Tungsten with collet & collet bodies, 1 ea 1/4”, 5/16”, 3/8”

alumina cup, 15’ cable with clamp & T25 dinse plug

Dinse Connector 10-1068 T25mm Dinse style male plug

Adaptor 10-4003 8-pin male to 14-pin female (6”)

Hand Held Pendant 10-4014 Includes contactor On/Off switch and current control with 25ft cable

and 8-pin male plug

Foot Control 10-4015 Contactor On/Off and current control with 15ft cable and 8-pin male plug

10-4016 Contactor On/Off and current control with 25ft cable and 8-pin male plug

Extension Cable 10-4017 3ft with 8-pin male plug and 8-pin female cable receptacle

10-4018 15ft with 8-pin male plug and 8-pin female cable receptacle

10-4019 25ft with 8-pin male plug and 8-pin female cable receptacle

10-4020 50ft with 8-pin male plug and 8-pin female cable receptacle

10-4021 75ft with 8-pin male plug and 8-pin female cable receptacle

Torch Switch On/Off 10-4006 15ft torch mounted with 8-pin male plug

10-4007 25ft torch mounted with 8-pin male plug

Torch Switch On/Off w/current

control

10-4008 15ft torch mounted with 8-pin male plug - adapts to 5/8”-7/8” torch

10-4009 15ft torch mounted with 8-pin male plug - adapts to 7/8”-1-1/8” torch

handle

10-4010 15ft torch mounted with 8-pin male plug - adapts to 1-1/8”-1-3/8” torch

handle

10-4011 25ft torch mounted with 8-pin male plug - adapts to 5/8”-7/8” torch

10-4012 25ft torch mounted with 8-pin male plug - adapts to 7/8”-1-1/8” torch

handle

10-4013 25ft torch mounted with 8-pin male plug - adapts to 1-1/8”-1-3/8” torch

handle

600296 Rotary amperage control 5k 15’ velcro for TD8

600297 Rotary amperage control 5k 25’ velcro for TD8
