User guide

ARCMASTER
®
160 S
March 31, 2006 3-3
3.04 Specifi cations
Parameter 160 S
CAV032CAV511tuptuO detaR
06158serepmA
7232stloV
%53%001elcyC ytuD
Duty Cycle TIG
160A / 17V @ 35% 230VAC
130A / 15V @ 60% 230VAC
100A / 14V @ 100% 230VAC
85A / 13V @ 100% 115VAC
STICK
160A / 27V @ 35% 230VAC
130A / 25V @ 60% 230VAC
100A / 24V @ 100% 230VAC
85A / 23V @ 100% 115VAC
Output Current TIG 5 – 160 (230V), 5 – 85 (115V)
Range STICK 5 – 160 (230V), 5 – 85 (115V)
Open Circuit Voltage 65V
Dimensions
Width
Height
Length
5.12” (130mm)
10.24” (260mm)
12.60” (320mm)
)gk 6.8( .sbl 59.81thgieW
Output @ Rated Load
Rated Input Voltage Single Phase 115VAC Single phase 230VAC
Output Amperes 160AA58
Output Volts V72V32
Duty Cycle %53%001
KVA 7.84.4
KW 2.54.2
Output @ No Load
KVA
KW
0.5
0.3
Input Volts Single Phase
115V
230V
Amperage Draw @ Rated Load
40
39
No Load
2.2
1.6
Thermal Arc continuously strives to produce the best product possible and therefore reserves the right to change,
improve or revise the specifi cations or design of this or any product without prior notice. Such updates or
changes do not entitle the buyer of equipment previously sold or shipped to the corresponding changes, updates,
improvements or replacement of such items.
The values specifi ed in the table above are optimal values, your values may differ. Individual equipment may
differ from the above specifi cations due to in part, but not exclusively, to any one or more of the following;
variations or changes in manufactured components, installation location and conditions and local power grid
supply conditions.
