Installation Guide

2
Aug. 2019
SP-6K-SS
1. GENERAL INFORMATION
1.1 SPECIFICATIONS
Specifications SP-6K-SS
Capacity 6,000 lbs.
Width Overall (pump mounted on back) 110-7/16”
Width Overall (pump mounted on side) 106-5/16”
Height Overall 110-1/4”
Length Overall 185-13/16”
Undercar clearance 76-15/16”
Drive Over Base Ramp Height 3”
Runway Width 18-7/8”
Runway Length 151–15/16”
Clearance Between Runways 39-3/8” – 42-1/2”
Approach Ramp Length 30-3/4”
Power Supply 110 VAC, 1PH, 20 Amp
