Installation Guide

16
Aug. 2019
SP-6K-SS
SP-6K-SS Parts list
ITEM
CODE
DESCRIPTION
QTY
1 SP-6K-SS-001 DJ05-01000-000 Base Plate 1
2 SP-6K-SS-002 DJ05-10000-000 Anchor Bolt, 3/4” x 5.5” 10
3 SP-6K-SS-003 5105-16050-000 Bolt, M16x x50mm 10
3-1 SP-6K-SS-003.1 5301-00020-000 Flat Washer, D20 10
4 SP-6K-SS-004 DJ05-02000-000 Column 1
5 SP-6K-SS-005 5105-06030-000 Screw, M6x x30mm 4
6 SP-6K-SS-006 DJ01-00005-M00 Upper Cover 1
7 SP-6K-SS-007 5101-20040-000 Bolt, M20 x 40mm 12
8a-1 SP-6K-SS-008A.1 DJ05-00005-D00 * Drip Tray, End Rail 4
8a-2 SP-6K-SS-008A.2 DJ05-00021-D00 * Drip Tray, Middle Rail 2
9 SP-6K-SS-009 5105-06025-000 Screw, M6 x 25mm 12
10 SP-6K-SS-010 5107-06015-000 Screw, M6 x 15mm 4
11a SP-6K-SS-011A DJ05-00001-000 4” Front Stop-A 2
12 SP-6K-SS-012 DJ05-03000-A00 Platform 2
13 SP-6K-SS-013 DJ01-13000-000 Cylinder 1
13-4 SP-6K-SS-013.4 5906-00030-000 Dust Ring 1
13-5 SP-6K-SS-013.5 DJ01-21002-M00 Guide Ring 1
13-6 SP-6K-SS-013.6 DJ05-13002-000 Piston Bar 1
13-7 SP-6K-SS-013.7 DJ01-21003-M00 Sheave 1
13-8 SP-6K-SS-013.8 5901-00030-000 O-Ring 1
13-9 SP-6K-SS-013.9 DJ01-21004-M00 Guide Belt 1
13-10 SP-6K-SS-013.10 5901-00066-000 O-Ring 1
13-11 SP-6K-SS-013.11 5905-00065-000 U-Ring 1
13-12 SP-6K-SS-013.12 DJ01-21005-M00 Piston 1
13-13 SP-6K-SS-013.13 DJ01-21006-M00 Nut 2
13-1 SP-6K-SS-013.1 5205-00024-000 Thin Nut 1
13-2 SP-6K-SS-013.2 DJ01-00013-M00 Round Nut 2
13-3 SP-6K-SS-013.3 DJ01-20000-M00 Roller Seat 1
13-14 SP-6K-SS-013.14 DJ01-00031-M00 Straight Connector 1
13-15 SP-6K-SS-013.15 DJ01-00030-M00 Throttle Washer 1
13-16 SP-6K-SS-013.16 5309-00010-000 Circlip, D10 1
13-17 SP-6K-SS-013.17 5603-00016-000 Combined Seal, D16 1
13-18 SP-6K-SS-013.18 DJ01-13100-000 Cylinder Body 1
13-19 SP-6K-SS-013.19 DJ01-12002-000 Roller Pin 1
13-20 SP-6K-SS-013.20 DJ01-00014-M00 Roller 1
13-21 SP-6K-SS-013.21 5303-00024-000 Spring Washer 1
13-22 SP-6K-SS-013.22 5901-00006-000 O-Ring 1
13-23 SP-6K-SS-013.23 DJ01-00021-M00 Hose 1
13-24 SP-6K-SS-013.24 SJ01-12001-000 Angle Connector 1
14 SP-6K-SS-014 DJ05-11000-000 Chain 1
15 SP-6K-SS-015 DJ01-00004-M00 Chain Pin 2
16 SP-6K-SS-016 5105-16060-000 Bolt, M16 x 60mm 2
17 SP-6K-SS-017 5303-00016-000 Spring Washer, D16 21
18 SP-6K-SS-018 DJ01-00001-M00 Chain Block (down) 1
20 SP-6K-SS-020 5201-00020-000 Nut, M20 12
21 SP-6K-SS-021 DJ01-00003-M00 Chain Block (upper) 1
22 SP-6K-SS-022 5404-03020-000 Split Pin 4
23 SP-6K-SS-023 DJ05-09000-000 Ramp 2
24 SP-6K-SS-024 DJ05-00004-000 Nylon Roller 4
25 SP-6K-SS-025 5304-00020-000 Circlip 4
26 SP-6K-SS-026 DJ01-12000-M00 Carriage 1
27 SP-6K-SS-027 5206-00030-000 Lock Nut, M30 x 1.5mm 1
29 SP-6K-SS-029 DJ01-13002-M00 Lock Tongue 1
30 SP-6K-SS-030 5206-00010-000 Lock Nut, M10 1
