Installation Guide

12
Aug. 2019
SP-6K-SS
RAISING A VEHICLE
Drive the vehicle onto the platform through ramps until it is about centered. Set the parking brake.
Depress the START button on power unit and the vehicle will rise. Raise the vehicle until it’s near the
ceiling of the garage.
WARNING!!
BE CAREFUL NOT TO RAISE THE VEHICLE SO HIGH THAT IT STRIKES THE CEILING! MAKE SURE
ANTENNAS ARE REMOVED, IF NECESSARY. ALSO BE AWARE OF ANYTHING THAT PROTRUDES
FROM THE CEILING, LIKE LIGHTBULBS, GARAGE DOOR OPENERS OR DOOR TRACKS. IT IS VERY
HELPFUL IF YOU HAVE A “SPOTTER” ON A LADDER TO TELL YOU WHEN YOU ARE NEAR THE
CEILING FOR THE FIRST LIFT!
Fig.19
A & B Ramp & Ramp Support
In order to maximize the height underneath the platforms, the ramp support shall be pulled backwards. The ramp
rests on the support as in Fig.19 A. Before loading or unloading the vehicle on the platform, the ramp support shall
be pushed forward to allow for ramps for pivot down, as shown in Fig.19 B.
