FRONT VIEW MODEL 2340/2540 M, MK
No. Description No. Description
1. Water reservoir cover 11. Thermostat (B10) knob
2. Water reservoir 12. Multipurpose valve
3. Safety valve 13. Front legs
4. Air trap jet 14. Rear legs
5. Pressure gauge 15. Reservoir water drain valve
6. Main power switch 16. Door closing device
7. Timer 17. Door microswitch
8. Power indicator light 18.
Door cover
9. Heat indicator light 19. Autoclave cover
10. Dry indicator light
16
14
13
11
12
8
9
10
5
6
7
19
18
1 2 3 4
17
15
