FRONT VIEW MODEL 1730 M, MK-Valueklave
No. Description No. Description
1. Front legs 10. Air trap jet
2. Reservoir water drain valve 11. Main power switch
3. Door closing device 12. Pressure gauge
4. Door microswitch 13. Power indicator light
5. Autoclave cover 14. Heat indicator light
6. Timer 15. Dry indicator light
7. Water reservoir cover 16. Multipurpose valve
8. Water reservoir 17. Thermostat (B10) knob
9. Safety valve 18. Door cover
18
12
6
11
5
4
10
9
8
7
2
3
13
14
15
16
17
1
