User Guide / Guide d’Utilisation
Package Contents / Contenu de la boîte GAME CHAT ON MIC E MUT GAME DXL1 Headset / Casque DXL1 DSS2 Surround Sound Processor / Processeur de Son Surround DSS2 ON MIC MUTE GAME Dolby® Surround Sound Gaming Headset / Casque pour jeux vidéo avec son Surround Dolby CHAT TURTLEBEACH.
Amplifier Amplificateur Using the /Amplifier DSS2 - Front / Avant 4 3 1. USB Output 2. Headphone Output Jack 3. Volume Control 4. Digital Input LED 5. Dolby® Digital LED 6. Surround Sound LED 7. Power LED 8. Equalizer Button 9. Surround Angles Button 10. Surround Sound On/Off ON MIC MUTE 1. Chat Volume 2. Game Volume 3. Mic Mute LED 4. Mic Mute Switch GAME 2 1 CHAT 1 FRANCAIS 1. Chat Volume 2. Game Volume 3. Mic Mute LED 4. Mettez Mic Mute PORTUGUÊS 1. Chat Volume 2. Volume Jogo 3.
DSS2 - Rear / Arrière XBOX 360® Setup / Configuration XBOX 360 11. Auxiliary Input 12. Analog Input 13. Digital Input 14. USB Input 15. Power Switch 4 2 3 USB Cable / Câble USB 1 OR GAME ON MIC MUTE CHAT Digital Optical Cable / Câble optique numérique ITALIANO 11. Ingresso ausiliario 12. Ingresso analogico 13. Ingresso digitale 14. Ingresso USB 15. Interruttore di accensione ESPAÑOL 11. Entrada auxiliar 12. Entrada analógica 13. Entrada digital 14. Entrada USB 15.
DANSK 1. Forbind det optiske kabel 2. Forbind USB-kablet 3. Tænd for DSS2 4. Forbind headsettet REMARQUE: les anciens modèles de Xbox 360 nécessitent un câble adaptateur audio HDMI Xbox 360 pour sortie audio optique (vendu séparément). Si votre télévision haute définition comporte une prise de sortie AUDIO OUT optique, vous pouvez l’utiliser pour brancher le câble optique au DSS2 et acheminer le son de la console de jeu au DSS2.
Configure Xbox 360® System Settings / Configurer les paramètres système Xbox 360 Connect the music player to the Auxiliary Input if you want to hear music with the game audio. Digital Output Digital Stereo Dolby Digital 5.1 Dolby Digital 5.1 with WMA Pro Select Connecting a Digital Music Player / Branchement d’un lecteur musical numérique Current Setting Dolby Digital Choose the digital output type for your system. This setting only applies to optical digital and HDMI audio outputs.
Surround Sound Angles / Angles du Son Surround Press the Surround Angles button to cycle through 6 different surround sound angles.
Equalizer (EQ) Presets / Préréglages de l’égalisateur Press the Equalizer button to cycle through the EQ presets. Double press the button to turn off the preset. EQ Presets: 1. Flat 2. Bass Boost 3. Aggressive Bass Boost 4. Treble Boost 5. Aggressive Treble Boost 6. Bass + Treble Boost 7. Aggressive Bass + Treble Boost 8. Mid-Range Boost 9. Aggressive Mid-Range Boost FRANCAIS Préréglages de l’égalisateur Appuyez sur le bouton d’égalisateur pour en faire défiler les préréglages.
Safety Notice / Avis de sécurité To avoid potential damage to the device, always disconnect all cables before transporting it. WARNING: Permanent hearing damage can occur if a headset is used at high volumes for extended periods of time, so it is important to keep the volume at a safe level. Over time, your ears adapt to loud volume levels, so a level that may not cause initial discomfort can still damage your hearing.
T CHA Technical Specifications ON MIC MUTE DXL1 Headset ON MIC MUTE CHAT GAME GAME GAME • 50mm diameter speakers • Speaker Frequency Response: 20Hz - 20kHz, >120dB SPL @ 1kHz • Condenser Microphone Frequency Response: 50Hz - 15kHz • Cable length: 16 ft.
EC Declaration of Conformity Manufacturer: Manufacturers Address: Product Name: Type of Product: Model Number(s): Year of Manufacture: FCC Declaration of Conformity Voyetra Turtle Beach 150 Clearbrook Rd. Suite 162, Elmsford, NY 10523 Ear Force XL1 Wired Headset TB300-2149-01 2011 We, Voyetra Turtle Beach, Inc.
EC Declaration of Conformity Manufacturer: Manufacturers Address: Product Name: Type of Product: Model Number(s): Year of Manufacture: FCC Declaration of Conformity Voyetra Turtle Beach 150 Clearbrook Rd. Suite 162, Elmsford, NY 10523 Ear Force DSS2 Dolby Surround Sound Adapter TB300-2200-01 2011 We, Voyetra Turtle Beach, Inc.
Limited Warranty for Turtle Beach Products Voyetra Turtle Beach, Inc. ("VTB") warrants to the original end-user purchaser ("Purchaser") that the retail Turtle Beach hardware product herein ("Product") will be free of defects in materials and workmanship for a period of one year from the date of purchase by the Purchaser ("Warranty Period"). Any Extended Warranty or Service Plans purchased through a Retail store are not honored by VTB.
Federal Communications Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
TB521-2123-01 Join Join The The Conversation Conversation // Participez Participez àà la la conversation conversation
