Specification Sheet

Turbo Air : 800-627-0032
Warranty : 800-381-7770
GK : 800-500-3519
AC : 888-900-1002
Ver.20171106
363/4 (933mm)
261/2 (673mm)
171/2 (443mm)
271/2 (698mm)
32 3/4 (832mm)
181/2 (469mm)
PLAN VIEW
Model : TBC-36SD/SB-N6
FRONT VIEW
PLAN VIEW
Bottle Coolers
Bottle Coolers
115/60/1
NEMA 5-15P
1.6
1/8
R-600a
8.5
12 Cases / 15 Cases
8.5
36
3/4 (933mm)
26
1/2 (673mm)
33
1/4 (845mm)
190
221
2
(unit : inch)
Underbar Equipment
Super Deluxe Series
SIDE VIEW
331/4 (845mm)
261/2 (673mm)
311/4 (793mm)
223/4 (577mm)
283/8 (721mm)
2”
ELECTRICAL DATA
DIMENSIONAL DATA
Voltage
Plug Type
Full Load Amperes
Compressor HP
Refrigerant
Cord Length (ft.)
Capacity (12oz.btls./12oz.cans)
Net Capacity (cu. ft.)
Ext. Length Overall (in.)
Ext. Depth Overall (in.)
Ext. Height Overall (in.)
Net Weight (lbs.)
Gross Weight (lbs.)
# of Dividers
# of Casters
*
†
* Depth does not include 2” for cap catcher or 2” for rear spacers.
† Height does not include 5” for caster height.
‡ Case capacity refers to 24 pack.
Design and specifications subject to change without notice.
Actual shipping weight may differ due to extra packing materials for product protection.
OPTIONAL ACCESSORIES :
2” caster for underbar series, ½” diameter: P0165B0100 (non-brake),
P0165B0110 (w/ brake
5” caster, ½” diameter & 13 TPI: M726500100 (non-brake),
M726500200 (w/ brake)
6” adjustable stainless steel leg: P0121P0100
5EA
‡
3 YEAR
(
U.S.A only
)
5 YEAR
Compressor
WARRANTY
(
U.S.A only
)
ISO 9001:2008
3 Year Parts and Labor Warranty
Additional 2 Year Warranty on Compressor
Anti-corrosion coated evaporator
Self-contained system
4” dia. swivel casters standard
5
