STEP 10 LEG PRESS CABLE ASSEMLY
14 AP-7000 SERIES LEG PRESS STATION
Assembly List
Item # Description Qty.
3 CABLE ADJUSTER 1
12 LEG PRESS CABLE 1 34 BUTTON HEAD SCREW GR-8 N/P 3/8-16 X 1 3/4 1 46 FINISHED HEX NUT N/P 1/2-13 1 48 FLAT WASHER SAE N/P 3/8” 2 52 NYLON INSERT LOCK NUT N/P 3/8-16 1 53 NYLON INSERT LOCK NUT N/P 5/16-18 1 54 NYLON PULLEY 3/8 X 1 X 4 1/2 BLACK 1 65 SHOULDER BOLT N/P 3/8 X 3/4 1 71 SPLIT BOLT GR-8 N/P 1/2-13 X 1 1 72 SPLIT LOCK WASHER N/P 1/2” 2 74 STRAP BRACKET 20 #SF20 STAINLESS STEEL 1
