AMERICA’S PREMIER EXERCISE EQUIPMENT OWNER’S MANUAL LEG PRESS STATION AP-71LP Rev0 Revision Date 10-21-09
Introduction A bout the LEG PRESS STATION. Congratulations on your new purchase of the LEG PRESS STATION. We hope you are completely satisfie with this pro uct an wish you many years of en oyment. T uff Stuff Equipment This Tuffstuff pro uct has een uilt to precise uality stan ar s an has een carefully pac age to ensure that amage will not occur uring shipment.
INDEX IMPORTANT ASSEMBLY INSTRUCTION NOTE..................4 FIRST STEPS FOR A SINGLE STATION...................................5 MULTIPLE STATION ASSEMBLY STEPS.................................7 LEG PRESS CABLE......................................................................14 EXPLODED VIEW.......................................................................19 PARTS LIST...................................................................................20 MAINTENANCE.................................
IMPORTANT ASSEMBLY INSTRUCTION NOTE INSTRUCTIONS FOR A SINGLE STATION ASSEMBLY ONLY: FOR STEPS 1 AND 2 YOU WILL NEED SOME HARDWARE THAT IS PROVIDED IN THE AP-70RP BOX. ONCE YOU COMPLETE STEPS 1 AND 2 SKIP TO STEP 5 TO RESUME INSTALLATION. INSTRUCTIONS FOR A MULTI STATION ASSEMBLY ONLY: BEGIN ASSEMBLY IN STEP 3. FOR STEPS 3 AND 4 YOU WILL NEED SOME HARWARE THAT IS PROVIDED IN THE AP-70CP BOX.
AP-7000 SERIES LEG PRESS STATION 5 B8 B9 B9 B8 STEP 1 B7 B 11 B1 69 48 8 B 11 B7 73 NYLON INSERT LOCK NUT N/P 3/8-16 SOCKET CAP SCREW GR-8 N/P 3/8-16 X 3 B9 B11 FLAT WASHER SOCKET CAP SCREW GR-8 N/P 3/8-16 X 3/4 SPLIT LOCK WASHER N/P 3/8” 48 69 73 15 MAIN FRAME 15 CROSS BRACE FLAT WASHER N/P 3/8 ID X 1 1/2 OD X 3/16 B8 8 FLAT WASHER SAE N/P 3/8” B7 Description REAR POST B1 Item # Assembly List 4 4 4 1 1 4 4 4 4 1 Qty.
AP-7000 SERIES LEG PRESS STATION B7 B11 STEP 2 50 50 60 18 21 10 22 19 B9 44 17 B11 B7 B8 SOCKET CAP SCREW GR-8 N/P 3/8-16 X 3 GUIDE RODS 3/4 RD X 71 3/4 B11 10 10 LB STEEL WEIGHT PLATE BLACK 4 9/16 X 9 7/16 10 LB TOP PLATE W/ADJ SLTR BAR 19 BLK WTS DECAL-WEIGHT NUMBERS REF TP-10 (200 lbs) FLAT WASHER N/P 3/4 X 2 21 22 44 50 RUBBER DONUT 3/4 X 2 1/2 TOP GUIDE ROD HOUSING 19 60 SPACER 1 ID X 1 1/4 OD X 2 18 SELECTOR PIN W/COIL 3/8 X 4 GOLD KNOB NYLON INSERT LOCK NUT N/P 3/8-16
AP-7000 SERIES LEG PRESS STATION 7 STEP 3 A7 A10 A1 69 48 A10 A8 8 73 FLAT WASHER SOCKET CAP SCREW GR-8 N/P 3/8-16 X 3/4 SPLIT LOCK WASHER N/P 3/8” 48 69 73 15 MAIN FRAME SPLIT LOCK WASHER N/P 3/8” A10 15 FLAT WASHER SAE N/P 3/8” A8 CROSS BRACE SOCKET CAP SCREW GR-8 N/P 3/8-16 X 1 A7 8 CENTER POST Description A1 Item # Assembly List 4 4 4 1 1 4 4 4 1 Qty.
AP-7000 SERIES LEG PRESS STATION A10 A8 A7 STEP 4 18 60 21 10 22 50 50 19 44 17 A10 A8 A7 DECAL-WEIGHT NUMBERS REF TP-10 (200 lbs) FLAT WASHER N/P 3/4 X 2 RUBBER DONUT 3/4 X 2 1/2 44 50 60 TOP GUIDE ROD HOUSING 19 10 LB TOP PLATE W/ADJ SLTR BAR 19 BLK WTS SPACER 1 ID X 1 1/4 OD X 2 18 22 SELECTOR PIN W/COIL 3/8 X 4 GOLD KNOB 17 10 LB STEEL WEIGHT PLATE BLACK 4 9/16 X 9 GUIDE RODS 3/4 RD X 71 3/4 10 21 SPLIT LOCK WASHER N/P 3/8” FLAT WASHER SAE N/P 3/8” A8 A10 SOCKET CAP
STEP 5 Assembly List Item # Description Qty.
STEP 6 Assembly List Item # Description Qty.
STEP 7 Assembly List Item # 67 Description Qty.
STEP 8 Assembly List Item # Description Qty.
STEP 9 Assembly List Item # Description Qty.
AP-7000 SERIES LEG PRESS STATION CABLE ADJUSTER LEG PRESS CABLE BUTTON HEAD SCREW GR-8 N/P 3/8-16 X 1 3/4 FINISHED HEX NUT N/P 1/2-13 FLAT WASHER SAE N/P 3/8” NYLON INSERT LOCK NUT N/P 3/8-16 NYLON INSERT LOCK NUT N/P 5/16-18 NYLON PULLEY 3/8 X 1 X 4 1/2 BLACK SHOULDER BOLT N/P 3/8 X 3/4 SPLIT BOLT GR-8 N/P 1/2-13 X 1 SPLIT LOCK WASHER N/P 1/2” STRAP BRACKET 20 #SF20 STAINLESS STEEL 12 34 46 48 52 53 54 65 71 72 74 Description 3 Item # Assembly List 1 2 1 1 1 1 1 2 1
AP-7000 SERIES LEG PRESS STATION 15 72 65 46 3 74 53 12 NOTES: 1. SOME PARTS CUT OUT/NOT SHOWN FOR CLARITY.
STEP 11 CABLE ASSEMBLY FINAL STEP Assembly List Item # Description Qty.
STEP 12 Assembly List Item # Description Qty.
STEP 13 Assembly List Item # Description Qty.
2 63 70 11 70 36 28 16 19 48 35 77 4 72 49 51 47 48 67 64 48 54 52 59 72 47 20 10 24 44 56 32 45 48 47 76 6 1 32 58 56 31 48 48 52 76 20 58 7 52 27 47 34 72 77 25 58 62 73 14 67 34 50 49 55 69 73 27 25 61 9 8 48 52 19 15 69 73 48 48 76 82 51 48 30 52 48 33 43 60 13 58 78 50 38 67 54 34 18 25 13 32 67 22 33 73 14 35 48 17 38 29 25 52 21 66 29 5 70 78 30 57 80 23 79 34 81 52 AP-7000 SERIES LEG PRESS STATION
COLOR CHART GRAY= SUB-ASSEMBLY PARTS BLACK= HARDWARE AP-71LP REV0 AP-71LP Parts List Item No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 Description Rev.
Maintenance TuffStuff Basic Strength Equipment Safety and General Maintenance All TUFFSTUFF strength equipment is designed and manufactured to offer maximum, long-life service with minimal maintenance. However, safety inspection and routine maintenance in your facility should be the upmost importance in your daily operation. Information presented in these pages will serve as a basic guideline to design your own inspection procedures.
Maintenance Part Three: Lubrication Bearing and linear bearings systems have advanced over the years but they must be maintained on a regular basis if you expect them to last and perform efficiently. TuffStuff uses only the highest quality bearings and linear motion components that are virtually trouble-free but requires the regular preventive maintenance to insure long-lasting performance. 1.
DO NOT DISCARD THIS MANUAL TUFFSTUFF LIMITED WARRANTY TuffStuff warrants to the original purchaser that TuffStuff equipment will be free from defects in material and workmanship. All warranty periods begin to run from the date of delivery to the original purchaser. The warranty and remedies set forth herein are conditioned upon proper storage, installation, use and maintenance and conformance with any recommendations of TuffStuff.
