Specification Sheet

Electrical Characteristics
1.0-500.0MHz Impedance (ohms)
1.0-500.0MHz Delay Skew (ns/100m)
Pair-to-Ground Capacitance
Unbalance (pF/100m)
Max. Conductor DC Resistance
20oC (ohms/km)
Resistance Unbalance (%)
100 ± 15
<=45
<=3300
72.2
<=5
Frequency MHz Return Loss Attenuation Next
Min (dB) Max (dB/100m) (Min dB)
1 20.0 2.0 65.3
4 23.0 4.1 56.3
8 24.5 5.8 51.8
16 26.0 8.2 47.3
20 26.5 9.3 45.8
62.5 25.0 17.0 38.4
100 25.0 22.0 35.3
200 18.0 32.4 30.8
250 17.3 36.9 29.3
300 16.8 41.0 28.2
350 16.3 44.9 27.2
400 15.9 43.0 35.3
550 14.9 51.8 33.2
Frequency MHz PSNEXT ELFEXT PSELFEXT Delay
Min (dB) Min (dB/100m) Min (dB/100m) Max (ns/100m)
1 62.3 63.8 60.8 570.0
4 53.3 51.7 48.7 552.0
8 48.8 45.7 42.7 546.7
16 44.3 39.7 36.7 543.0
20 42.8 37.7 34.7 542.0
62.5 35.4 27.8 24.8 538.6
100 32.3 23.8 20.8 537.6
200 27.8 17.7 14.7 536.5
250 26.3 15.8 12.8 536.3
300 25.2 14.2 11.2 536.1
350 24.2 12.9 9.9 535.9
400 33.3 12.8 9.5 535.8
550 31.2 12.5 9.2 535.5
We ship direct from our
high service factory.
Forever Warranty.
Forever Covered.
800.719.8277 truecable.com
 
Mechanical Characteristics
Test Object Jacket
Test Material PVC
Before Tensile Strength (Mpa) >=13.8
Aging Elongation (%) >=100
Aging Condition (°Cxhrs) 100x168
After Tensile Strength (Mpa) >=85% of unaged
Aging Elongation (%) >=50% of unaged
Cold Bend (-20+2° Cx4hrs) No Crack
Cat6
Unshielded Riser
23AWG • 4 Twisted Pairs • CMR • UTP
550MHz • Solid Copper
Packaging Available
• 500ft Reel
• 1000ft Pull Box
Jacket Colors
