installation guide

20
TRUE RESIDENTIAL
®
25
23/32
"
viewable
area
19
5/8
"
viewable
area
10
5/8
"
viewable
area
CUSTOM PANEL INSTALLATION - GLASS DOOR REFRIGERATOR
24 INCH 15 INCH
SOLID DOOR 24 INCH 15 INCH
DOOR PANEL WIDTH 23
5/8
" 14
5/8
"
DOOR PANEL HEIGHT 29
23/32
" 29
23/32
"
DOOR PANEL DEPTH 3/4" max 3/4" max
DOOR PANEL WEIGHT 10 lb. max 10 lb. max
RAIL / STYLE DIMENSION 2" min 2" min
6 1/8"
14 7/8"
23 5/8"
29 23/32"
29/32"
7 5/16"
14 5/8"
5 29/32"
6 1/8"
14 7/8"
23 5/8"
17 23/32"
23 5/8"
29 23/32"
29/32"
29/32"
29/32
