Spec Sheet

STANDARD FEATURES
Model:
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
PLAN VIEW
KCL
TRUE MANUFACTURING CO., INC.
2001 East Terra Lane • O’Fallon, Missouri 63366-4434 • [phone] • Fax [phone] • Toll Free [phone] • Intl. Fax# [phone] • www.truemfg.com
WARRANTY
Three year warranty on all parts
and laborand an additional 2 year
warranty on compressor.
(U.S.A. only)
ELEVATION PLAN VIEW
83
5
/ 16 "
(2117 mm)
78
5
/16 "
(1990 mm)
5 "
(127 mm)
54
1
/ 8 "
(1375 mm)
29
1
/ 2 "
(750 mm)
25
17
/ 32 "
(649 mm)
55
1
/ 32 "
(1398 mm)
1
3
/8 "
(35 mm)
76
15
/ 16 "
(1955 mm)
4"
(102 mm)
T-49DT-4-HC
T-Series:
Reach-In Solid Half Swing Door Dual Temperature
Refrigerator/Freezer with Hydrocarbon Refrigerant
Model Elevation Right Plan 3D Back
T-49DT-4-HC
DESIGN
•
True’s solid door reach-in’s are designed with
enduring quality that protects your long term
investment.
•
True’s commitment to using the highest
quality materials and oversized refrigeration
systems provides the user with colder product
temperatures, lower utility costs, exceptional food
safety and the best value in today’s food service
marketplace.
REFRIGERATION SYSTEM
•
Equipped with two, independent, factory
engineered, self-contained, capillary tube
refrigeration systems using environmentally
friendly environmentally friendly R290
hydrocarbon refrigerant that has zero (0) ozone
depletion potential (ODP), & three (3) global
warming potential (GWP).
•
Refrigerator located in left section; freezer in the
right.
•
High capacity, factory balanced refrigeration
system that maintain colder standard
temperatures for the best in food preservation.
Refrigerator holds 33°F to 38°F (.5°C to 3.3°C);
freezers holds -10°F (-23.3°C).
•
State of the art, electronically commutated
evaporator and condenser fan motors. ECM
motors operate at higher peak eciencies and
move a more consistent volume of air which
produces less heat, reduces energy consumption
and provides greater motor reliability.
•
Bottom mounted condensing units positioned
for easy cleaning. Compressors run in coolest and
most grease free area of the kitchen. Allows for
storage area on top of unit.
•
Automatic freezer defrost system time-initiated,
temperature-terminated. Saves energy
consumption and provides shortest possible
defrost cycle.
CABINET CONSTRUCTION
•
Exterior - Stainless steel front. Anodized quality
aluminum ends. Corrosion resistant GalFan coated
steel back.
•
Interior - attractive, NSF approved, clear coated
aluminum liner. Stainless steel oor with coved
corners.
•
Insulation - entire cabinet structure and solid
doors are foamed-in-place using a high density,
polyurethane insulation that has zero ozone
depletion potential (ODP) and zero global
warming potential (GWP).
•
Welded, heavy duty steel frame rail, black powder
coated for corrosion protection.
•
Frame rail tted with 4" (102 mm) diameter stem
castors - locks provided on front set.
DOORS
•
Stainless steel exterior with clear aluminum liners
to match cabinet interior. Doors extend full width
of cabinet shell. Door locks standard.
•
Lifetime guaranteed recessed door handles. Each
door tted with 12" (305 mm) long recessed
handle that is foamed-in-place with a sheet metal
interlock to ensure permanent attachment.
•
Positive seal self-closing doors. Lifetime
guaranteed door hinges and torsion type closure
system.
•
Magnetic door gaskets of one piece construction,
removable without tools for ease of cleaning.
SHELVING
•
Six (6) adjustable, heavy duty PVC coated wire
shelves 22 ⁄"L x 23 ¼"D (582 mm x 591 mm). Four
(4) chrome plated shelf clips included per shelf.
•
Shelf support pilasters made of same material as
cabinet interior; shelves are adjustable on ½" (13
mm) increments.
LIGHTING
•
Compartmentalized, interior lighting - safety
shielded. Lights activated by rocker switch
mounted above top doors.
MODEL FEATURES
•
Two (2) exterior digital temperature displays, one
for refrigerator section and one for freezer.
•
Evaporators are epoxy coated to eliminate the
potential of corrosion.
•
Freezer rear airow guards prevent product from
blocking optimal airow.
•
Minimum wattage heater in cabinet frame and
freezer door.
•
NSF/ANSI Standard 7 compliant for open food
product.
ELECTRICAL
•
Unit completely pre-wired at factory and ready
for nal connection to a 115/60/1 phase, 15 amp
dedicated outlet. Cord and plug set included.
OPTIONAL FEATURES/ACCESSORIES
Upcharge and lead times may apply.
❑ 6" ( 153 mm) standard legs.
❑ 6" (153 mm) seismic/anged legs.
❑ 2 ½" (64mm) castors.
❑ 2 ½" (64 mm) standard legs.
❑ Half door bun tray racks. Each holds up to eleven
18"L x 26"D (458 mm x 661 mm) sheet pans (sold
separately) (airow guard needs to be removed
from freezer).
❑ Additional shelves.
❑ Novelty baskets.
