Spec Sheet

STANDARD FEATURES
Model:
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
PLAN VIEW
KCL
TRUE MANUFACTURING CO., INC.
2001 East Terra Lane • O’Fallon, Missouri 63366-4434 • [phone] • Fax [phone] • Toll Free [phone] • Intl. Fax# [phone] • www.truemfg.com
3"
76mm
26 7/8"
683mm
15/32"
12mm
33 15/32"
850mm
36 9/16"
928mm
34 15/16"
887mm
36 1/32"
915mm
8 27/32"
224mm
21/32"
17mm
2 3/32"
53mm
26 7/8"
683mm
12 25/32"
325mm
24 25/32"
630mm
26 1/8"
663mm
1"
26mm
9 15/32"
240mm
32 9/16"
827mm
14 3/32"
358mm
TD-36-12-HC BLK
T-36-GC-HC
Underbar Refrigeration:
Solid Slide Lid Glass and Plate Chiller/Froster with
Hydrocarbon Refrigerant
Model Elevation Right Plan 3D Back
T-36-GC-HC
DESIGN
•
True’s glass and plate chiller/frosters
are designed with enduring quality and
value. Our commitment to using the
highest quality materials and oversized
refrigeration assures colder product
temperatures and years of trouble free
service.
REFRIGERATION SYSTEM
•
Factory engineered, self-contained,
capillary tube system using
environmentally friendly R290
hydrocarbon refrigerant that has zero
(0) ozone depletion potential (ODP),
& three (3) global warming potential
(GWP).
•
High capacity, factory balanced
refrigeration system that maintains
cabinet of 0°F (-17.7°C) and below.
•
State of the art, electronically
commutated evaporator and
condenser fan motors. ECM motors
operate at higher peak eciencies and
move a more consistent volume of
air which produces less heat, reduces
energy consumption and provides
greater motor reliability.
•
Automatic defrost system time-
initiated, time-terminated.
•
Condensing unit accessed from
behind front grill, slides out for easy
maintenance.
•
Forced-air cooling, positively guided
airow provide ecient balanced
temperatures throughout the cabinet.
CABINET CONSTRUCTION
•
Exterior - Stainless steel countertop
and lids, black powder coated cold
rolled steal front, sides, and back.
•
Interior - long lasting, heavy duty
galvanized steel.
•
Insulation - entire cabinet structure is
foamed-in-place using a high density,
polyurethane insulation that has zero
ozone depletion potential (ODP) and
zero global warming potential (GWP).
•
Welded, heavy duty steel frame rail,
black powder coated for corrosion
protection.
SHELVING
•
Three (3) adjustable, heavy duty PVC
coated wire shelves. One (1) bottom
shelf 18 ½"L x 19 ⁄"D (470 mm x 491
mm) and two (2) top shelves 16 ¼"L x
19 ⁄"D (413 mm x 493 mm). Split shelf
design allows for eective rotation of
chilled smallware, working with already
chilled plates and glasses on one side
while chilling dry product on the other
side.
MODEL FEATURES
•
Evaporator is epoxy coated to eliminate
the potential of corrosion.
•
Listed under NSF/ANSI Standard 7 for
the storage and/or display of packaged
or bottled product.
ELECTRICAL
•
Unit completely pre-wired at factory
and ready for nal connection to a
115/60/1 phase, 15 amp dedicated
outlet. Cord and plug set included.
OPTIONAL FEATURES/ACCESSORIES
Upcharge and lead times may apply.
❑ 6" (153 mm) standard legs.
❑ 6" (153 mm) seismic/anged legs.
❑ 2 ½" (64 mm) diameter castors.
❑ 3" (77 mm) diameter castors.
❑ Ratchet lock and handle.
❑ Floor racks.
(U.S.A. only)
