Spec Sheet

Specications subject to change without notice.
Chart dimensions rounded up to the nearest ⁄" (millimeters rounded up to next whole number).
ROUGH-IN DATA
Model:
Project Name:
Location:
Item #: Qty:
Model #:
AIA #
SIS #
TRUE MANUFACTURING CO., INC.
U.S.A. FOODSERVICE DIVISION
2001 East Terra Lane • O’Fallon, Missouri 63366-4434 • [phone]
Fax [phone] • Toll Free [phone] • Intl Fax# [phone]
Parts Dept. (800)424-TRUE • Parts Dept. Fax# [phone] • www.truemfg.com
Printed in U.S.A.
APPROVALS: AVAILABLE AT:
Exterior Color Options
Standard White Exterior Optional Black Exterior Optional Stainless Exterior
GDM-43F-HC~TSL01
INNOVATION
MADE WITH
IN THE USA
Glass Door Merchandiser:
Swing Door Freezer with Hydrocarbon Refrigerant~True Standard Look Version 01
GDM-43F-HC~TSL01
† Depth does not include 1⁄" (42 mm) for door handles.

The world’s #1 manufacturer of glass door
merchandisers.

Designed using the highest quality
materials and components to provide the
user with an attractive, point of purchase
merchandiser that brilliantly displays
frozen food and ice cream, resulting in high
impulse sales.

Factory engineered, self-contained, capillary
tube system using environmentally friendly
R290 hydro carbon refrigerant that has zero
(0) ozone depletion potential (ODP), & three
(3) global warming potential (GWP).

High capacity, factory balanced refrigeration
system that maintains -10°F (-23.3°C)
temperatures. Ideal for both frozen foods
and ice cream.

Exterior - non-peel or chip white powder
coated cold rolled steel; durable and
permanent.

Interior - attractive, NSF approved, white
aluminum interior liner with stainless steel
oor.

Self closing doors. Positive seal, torsion type
closure system.

Triple pane thermal insulated glass door
assembly with extruded aluminum frame.

LED interior lighting provides more even
lighting throughout the cabinet. Safety
shielded.

Entire cabinet structure is foamed-in-
place using a high density, polyurethane
insulation that has zero ozone depletion
potential (ODP) and zero global warming
potential (GWP).
Bottom mounted units feature

”No stoop” lower shelf to maximize product
visibility

Storage on top of cabinet.

Easily accessible condenser coil for cleaning.
Model Doors Shelves
Cabinet Dimensions
(inches)
(mm)
HP Voltage Amps
NEMA
Config.
Cord
Length
(total ft.)
(total m)
Crated
Weight
(lbs.)
(kg)W D† H
GDM-43F-HC~TSL01 2 8 47⁄ 29⁄ 78⁄ ½ 115/60/1 10.6 5-20P 9 550
1197 759 1998 N/A N/A 2.74 250
9/18
