Spec Sheet

STANDARD FEATURES
Model:
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
PLAN VIEW
KCL
TRUE MANUFACTURING CO., INC.
2001 East Terra Lane • O’Fallon, Missouri 63366-4434 • [phone] • Fax [phone] • Toll Free [phone] • Intl. Fax# [phone] • www.truemfg.com
WARRANTY
Three year warranty on all parts
and laborand an additional 2 year
warranty on compressor.
(U.S.A. only)
24 13/16"
630mm
53 3/8"
1356mm
3/16"
5mm
22 7/8"
581mm
1 19/32"
41mm
17/32"
14mm
25 1/32"
636mm
46 5/8"
1184mm
22 27/32"
580mm
GDM-10 HC~TSL01
R
GDM-10F-HC~TSL01
Glass Door Merchandiser:
Swing Door Freezer with Hydrocarbon
Refrigerant~True Standard Look Version 01
Model Elevation Right Plan 3D Back
GDM-10F-HC~TSL01
DESIGN
•
True’s commitment to using the highest
quality materials and oversized refrigeration
systems provides the user with colder product
temperatures, and lower utility costs in an
attractive merchandiser that brilliantly displays
frozen food and ice cream.
REFRIGERATION SYSTEM
•
Factory engineered, self-contained, capillary
tube system using environmentally friendly
R290 hydrocarbon refrigerant that has zero (0)
ozone depletion potential (ODP), & three (3)
global warming potential (GWP).
•
High capacity, factory balanced refrigeration
system that maintains -10°F (-23.3°C)
temperatures. Ideal for both frozen foods and
ice cream.
•
State of the art, electronically commutated
evaporator and condenser fan motors. ECM
motors operate at higher peak eciencies
and move a more consistent volume of air
which produces less heat, reduces energy
consumption and provides greater motor
reliability.
•
Bottom mounted condensing unit positioned
for easy maintenance. “No stoop” lower shelf
maximizes visibility by raising merchandised
product to higher level.
•
Automatic defrost system time-initiated,
temperature-terminated. Saves energy
consumption and provides shortest possible
defrost cycle.
CABINET CONSTRUCTION
•
Exterior - non-peel or chip white powder
coated cold rolled steel; durable and
permanent.
•
Interior - attractive, NSF approved, white
aluminum liner with stainless steel oor.
•
Insulation - entire cabinet structure is foamed-
in-place using a high density, polyurethane
insulation that has zero ozone depletion
potential (ODP) and zero global warming
potential (GWP).
•
Welded, heavy duty steel frame rail, black
powder coated for corrosion protection.
•
Frame rail tted with leg levelers.
•
Door sign decal. Variety of decal options
available.
DOOR
•
Triple pane thermal insulated glass door
assembly with mitered plastic channel frame.
•
Door tted with 12" (305 mm) long integrated
handle.
•
Self closing door. Positive seal, torsion type
closure system.
•
Magnetic door gasket of one piece
construction, removable without tools for ease
of cleaning.
SHELVING
•
Three (3) adjustable, heavy duty PVC coated
wire shelves 20 ⁄”L x 16¾”D (529 mm x
426 mm). Four (4) chrome plated shelf clips
included per shelf. One (1) PVC coated wire
oor rack 22 ⁄”L x 17 ½”D (568 mm x 445
mm).
•
Shelf support pilasters made of same material
as cabinet interior; shelves are adjustable on
½” (13 mm) increments.
LIGHTING
•
LED interior lighting, safety shielded.
MODEL FEATURES
•
Evaporator is epoxy coated to eliminate the
potential of corrosion.
•
See our website www.truemfg.com for latest
color and sign oerings.
•
Backguard and oor rack ensure optimum
airow.
•
Listed under NSF/ANSI Standard 7 for the
storage and/or display of packaged or bottled
product.
ELECTRICAL
•
Unit completely pre-wired at factory and
ready for nal connection to a 115/60/1 phase,
15 amp dedicated outlet. Cord and plug set
included.
OPTIONAL FEATURES/ACCESSORIES
Upcharge and lead times may apply.
❑ Left hinge model available.
❑ Black exterior.
❑ Stainless steel exterior.
❑ Black aluminum interior liner with black
shelving.
❑ Stainless steel interior liner.
❑ 2 ½" (64 mm) diameter castors.
❑ Novelty baskets.
❑ Additional shelves.
❑ Pricing strips.
❑ Barrel Locks located in grill assembly (requires
one per door)
