Data Sheet

Type
Color
Wire range
T1904C040
Insulator material: Vinyl
Terminal material: Copper
Working Temperature: 75°C max.
Rating
voltage: 600 V/AC max.
Rating current:
Red - 9 Amp. max.
Blue - 15 Amp. max.
Yellow - 20 Amp. max.
0.5-1.5 mm²
0.8 x 2.8 mm
Red
Insulated Crimp Female Disconnector Set
T1904C041
22-16 AWG
Contents
Red
T1904C106
1.5-2.5 mm²
0.5-1.5 mm²
16-14 AWG
22-16 AWG
Blue
25pcs
25pcs
25pcs
L1
L
6.5
18.6
Dimension(mm)
6.5
18.6
6.5
19.0
TAB
0.8 x 2.8 mm
0.8 x 4.8 mm
T1904C107
1.5-2.5 mm²
0.8 x 4.8 mm
Blue
T1904C038
16-14 AWG
Blue
T1904C039
0.5-1.5 mm²
1.5-2.5 mm²
22-16 AWG
16-14 AWG
Red
25pcs
25pcs
25pcs
6.5
19.0
7.7
21.0
7.5
20.5
0.8 x 6.3 mm
0.8 x 6.3 mm
Yellow
T1904C108
4.0-6.0 mm²
12-10 AWG
15pcs
7.5
23.5
0.8 x 6.3 mm
L
L1
2109195 / 2109165 / 2109202 / 2109169 / 2109191 / 2109212 / 2109170
