Operation Manual

27Section 7 — Service
Changing the Deck Belt
NOTE: It is possible to change the deck belt with the cutting
deck still installed on the tractor, however it is much easier to
remove the deck first, change the deck belt, then reinstall the
cutting deck.
To change the cutting deck belt, proceed as follows:
 It is easiest to change the deck belt by first removing the
cutting deck as instructed earlier in this section first. Skip
this step if deciding to change the deck belt with the

the cutting deck now.
2. If changing the deck belt with the cutting deck still
installed on the unit, lower the deck to the lowest mowing
position.
3. 
pulley as shown in Figure 7-2. Simply roll one side of the
belt off of the pulley and then work it off the pulley by
continuing around the pulley until the belt is off of the
pulley.
 Pull the belt towards the front of the unit, pulling it through
and out of the belt keeper rod, shown in Figure 7-2.
5. Remove the deck belt cover by removing the three hex
bolts that secure it. See Figure 7-5.
Figure 7-5
 Remove the belt keeper by removing the hex bolt that

Belt Keeper Hex bolt
Figure 7-6
7. Change the belt then reinstall the all the components
removed in the reverse order beginning with the idler
pulley, and then belt cover.
8. Feed the deck belt through the belt keeper rod and work it

Battery
CALIFORNIA PROPOSITION 65 WARNING!
Battery posts, terminals, and related accessories
contain lead and lead compounds, chemicals known
to the State of California to cause cancer and
reproductive harm. Wash hands after handling.
CAUTION: If removing the battery, disconnect the



(Red) wire its terminal first, followed by the
NEGATIVE (Black) wire.
Battery Failures
Some common causes for battery failure are:
 Incorrect initial activation
 
 Freezing
 Undercharging
 Corroded connections

