Operation Manual

Battery
The battery is sealed and is maintenance-free. Acid levels cannot
be checked.
 Always keep the battery cables and terminals clean and
free of corrosive build-up.
 After cleaning the battery and terminals, apply a light coat
of petroleum jelly or grease to both terminals.
 Always keep the rubber boot positioned over the positive
terminal to prevent shorting.
IMPORTANT: If removing the battery for any reason,



first, followed by the NEGATIVE (Black) wire. Be certain that the
wires are connected to the correct terminals; reversing them

alternating system.
Cleaning Battery
Clean the battery by removing it from the tractor and washing
with a baking soda and water solution. If necessary, scrape the
battery terminals with a wire brush to remove deposits. Coat
terminals and exposed wiring with grease or petroleum jelly to
prevent corrosion.
Adjustments
WARNING: Never attempt to make any
adjustments while the engine is running, except

Steering Adjustment
If the tractor turns tighter in one direction than the other, or if
the front tie rod is being replaced due to damage or wear, the
steering will need to be adjusted.
To Adjust the toe in/out of the front wheels:
 Remove the bow-tie clip securing the tie-rod ferrule to the
right front axle assembly, and drop the tie-rod down to

Figure 6-3
Steering Rack & Pinion

necessary to lubricate the steering rack and pinion gear located
under the front of the unit. Using standard automotive grease,
apply grease to the front side and rear side of the steering rack,

Figure 6-2
Cleaning the Engine And Deck
If the engine has been running, allow it to cool for at least half
an hour before cleaning. Periodically remove dirt build-up from
engine. Clean cooling fins every 25 hours. Clean with a brush or
compressed air.
IMPORTANT: Do not spray engine with water to clean because
water could contaminate fuel. Using a garden hose or pressure
washing equipment can also force water into the air cleaner or
muffler opening. Water in the air cleaner will soak the paper
element, and water that passes through the element or muffler
can enter the cylinder, causing damage.
Any fuel or oil spilled on the machine should be wiped off

fins of the engine or on any other part of the machine.
IMPORTANT: The use of a pressure washer to clean your

components, spindles, pulleys, bearings or the engine.
WARNING! Accumulation of debris around muffler
could cause a fire. Inspect and clean before every
use.
Muffler
WARNING! Temperature of muffler and nearby

contact with these areas.
Inspect muffler periodically, and replace if necessary.
Replacement parts for the muffler must be the same and
installed in the same position as the original parts.
22 Section 6— Maintenance & adjuStMentS
