Manual

TRITON SYSTEMS, INC.
5-55
OPERATION MANUAL - MODEL 9610 SECTION 5 - MANAGEMENT FUNCTIONS
FUNCTION: STORE MESSAGE
FACTORY DEFAULT: SEE NOTE
ACCESS INSTRUCTIONS:
1.) Select TERMINAL CONFIGURATION from the
MANAGEMENT FUNCTIONS menu.
2.) Select CHANGE MESSAGES.
3.) Select STORE MESSAGE.
DESCRIPTION:
The STORE MESSAGE consists of four lines of text that are printed
on the customer receipt. The text can be full alphanumeric text.
Enter letters, numbers and punctuation as follows:
The keys along either side of the display are used with the numeric
keys on the main keypad to permit entry of alphanumeric charac-
ters. The keys on the left side of the display are designated <F1>
through <F4>. The keys on the right side of the display are <F6>
through <F8>. The <F1> key centers the text on the line where the
cursor appears. The <F2> key erases all text in the current mes-
sage. <F3> clears the text on the line the cursor is currently ap-
pearing.
The <F4> Key is used similarly to a CAPS LOCK key on a com-
puter keyboard. Pressing the <F4> key toggles between upper-
case and lowercase. To enter an alphabetic or punctuation char-
acter, one of the <F6> through <F8> keys must be pressed, fol-
lowed by one of the numeric keys. The resultant character will be
as indicated in the table. Press the <OK> key to save the changes
made. If you make a mistake and want to start over, press the
CANCEL key to discard any changes made to that point.
NOTE: ‘*THIS IS LINE (1-4) OF THE STORE MESSAGE*’
E
RROR CONDITIONS:
There are no errors directly associated with this function.
YEK
4F
REPPU
1
2 3 4 5 6 7 8 9 0
tfihSoN 1234567890
tfeL6FQADGJMPTW,
retneC7F ZBEHKNRUX .
thgiR8FpSCFILOSVY-
4F
REWOL
tfihSoN!@#$%^&*()
tfeL6Fqadgjmptw’
retneC7Fzbchknrux+
thgiR8F&cfilosvy=
