Manual

TRITON SYSTEMS, INC.
5-73
OPERATION MANUAL - MODEL 9610 SECTION 5 - MANAGEMENT FUNCTIONS
FUNCTION: FAST CASH AMOUNT
FACTORY DEFAULT: PROCESSOR-SPECIFIC
ACCESS INSTRUCTIONS:
1.) Select TERMINAL CONFIGURATION from the
MANAGEMENT FUNCTIONS menu.
2.) Select SET TERMINAL PARAMETERS.
3.) Select CASSETTE SETUP.
4.) Choose the FAST CASH AMOUNT option.
D
ESCRIPTION:
During a withdrawal transaction the FAST CASH screen prompts
the customer to select the amount of the withdrawal from a list of
five convenient amounts. These amounts are entered by the ter-
minal operator using the FAST CASH AMOUNT function. Up to six
digits (more with software versions that support extended field
lengths) can be entered into any data field accepting a monetary
value.
Selecting this function displays the FAST CASH SCREEN
AMOUNTS screen. Press the screen key next to the amount to be
changed, and it will begin to blink. Enter the new amount (whole
dollar amount only), and then press the <OK> key. The value will
replace the blinking amount.
The amounts entered must be even multiples of the denomination
in the cassette. The amounts do not have to be in any particular
order, although typically, they increase in value moving from upper
left and down, then upper right and down. DO NOT enter an amount
that is larger than the MAXIMUM WITHDRAWAL AMOUNT.
ERROR CONDITIONS:
There are no error conditions directly associated with this function.
