Specification

Primary Form Factor Tower
Primary UPS Depth (mm) 345
Primary UPS Height (mm) 160
Primary UPS Width (mm) 122
Shipping Dimensions (hwd / in.) 9.80 x 7.20 x 16.30
Shipping Weight (kg) 6.99
UPS Housing Material ABS
UPS Power Module Dimensions
(hwd, in.)
6.3 x 4.8 x 13.6
UPS Power Module Weight (kg) 6.49
UPS Power Module Weight (lbs.) 14.3
ENVIRONMENTAL
Operating Temperature Range +32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
Storage Temperature Range +5 to +113 degrees Fahrenheit / -15 to +45 degrees Celsius
Relative Humidity Up to 90%, non-condensing
AC Mode BTU / Hr. (Full Load) 43
AC Mode Efficiency Rating (100%
Load)
>95%
Operating Elevation (ft.) Up to 10,000 ft.
Operating Elevation (m) Up to 3000m
COMMUNICATIONS
Communications Interface USB (HID enabled)
PowerAlert Software For local monitoring via the UPS’s built-in USB communications port, download PowerAlert Local
software at http://www.tripplite.com/poweralert
Communications Cable USB cable included
WatchDog Compatibility Supports Watchdog application, OS and hard-reboot restart options for remote applications
Network UPS Tools Compatibility
LINE / BATTERY TRANSFER
Transfer Time 6 milliseconds
Low Voltage Transfer to Battery
Power (Setpoint)
89
High Voltage Transfer to Battery
Power (Setpoint)
145
SPECIAL FEATURES
Cold Start (Startup in Battery Mode
During a Power Failure)
Cold-start operation supported
4 / 5
