USER GUIDE
14
Keyboard settings when replacing a computer
For Type the letters
PC (Windows, Linux,
Novell)
PC
UNIX console mode UC
UNIX graphics mode UG
Set the keyboard mode setting to:
• PC when operating Intel based computers.
• UC when operating UNIX computers in console mode.
• UG when operating UNIX computers in graphics mode.
Mouse driver settings when replacing a computer
For Type the letters
Wheel mouse or Intellimouse IN
2 or 3 button mouse PS
5-button mouse EP
