Datasheet

IP connection.
Remote authentication support - RADIUS and LDAP/S
Supports both IPv4 and IPv6
Accessing the connected computers is a breeze; a wide range of video and mouse sync settings ensure
optimal remote session performance in any situation.
Virtual Media allows an .iso file located in a Shared folder of a SAMBA or NFS server that is accessible to the
KVM to be mounted to a Target Server and accessed as if it were directly stored on it. (Virtual Media requires
that a B078-101-USB-1 be connected to each computer on which it is needed)
Supports the highest security standards for encryption (128-bit AES and HTTPS).
BIOS level control to any server’s brand and model, regardless of the server condition and network connectivity. Covers the entire spectrum of crash
scenarios.
PDU Control – Allows you to add IP PDU’s as devices that can be controlled by the KVM. Individual ports on the KVM can be assigned to a port on a
PDU, allowing you to Power Cycle or Power Off/On the computer/server connected to that port without leaving the KVM session screen.
Multi-Level account access – Administrator and User accounts can be created, with a password being required to access the KVM switch and your
assigned permissions. Administrator accounts have full access, while User accounts can be set up to access only the ports and features necessary to that
individual.
Dual Ethernet Ports – If one network port fails, the other takes over.
Dual Power Supplies – If one power supply fails, the other takes over.
Dual Serial Ports – Connect serial manageable devices, such as PDUs, firewalls, and routers.
Allows for system sent messages to SNMP server to notify of LAN or power failures.
Event log records events that take place on the installation, such as logins, reboots, network settings changes, etc..
Allows for the installation of a SSL certificate to ensure secure transactions between the Web servers and browsers.
Access and control the KVM via the graphical remote interface, or a text based local OSD.
Flash upgradeable firmware over the network.
Specifications
OVERVIEW
Users 5
PHYSICAL
Unit Dimensions (hwd / in.) 1.71 x 17.28 x 10.99
Unit Weight (lbs.) 7.75
Color Black
ENVIRONMENTAL
Storage Temperature Range -4 to 140 F (-20 to 60 C)
Relative Humidity 0 to 80% RH, Non-Condensing
Operating Temperature 32 to 104 F (0 to 40 C)
COMMUNICATIONS
Package Includes
B072-032-IP4 32-Port, 4+1 User
NetCommander Cat5 IP KVM
Switch
Rackmount hardware
(x2) Power cords
2 / 3
