OWNER’S MANUAL TRINITY PRO 4-TIER NSF CORNER WIRE SHELVING RACK Model # TBFZ-0927 / TBFPBA-0927 Important / Important / Importante FOR QUICK & EASY 3D ASSEMBLY INSTRUCTIONS POUR DES DIRECTIVES D’ASSEMBLAGE 3D RAPIDES ET FACILES Direct ives int elligent es Inst rucciones Int eligent es PARA INSTRUCCIONES DE ENSAMBLAJE RÁPIDAS Y SENCILLAS EN 3D DOWNLOAD THE FREE APP | TÉLÉCHARGER L’APPLICATION GRATUITE | DESCARGUE LA APLICACIÓN GRATUITA
PARTS LIST Your TRINITY PRO 4-Tier NSF Corner Wire Shelving Rack should include the following parts. Please inspect box contents to ensure you have received all components. If you are missing any parts, need assistance with assembly or have questions, please contact TRINITY Customer Service: 800.985.5506 or customerservice@trinityii.com. Parts can also be requested online at www.trinityii.com (Help & More, Contact Us). You will NOT need additional tools for assembly.
ASSEMBLY INSTRUCTIONS STEP 1 For easiest assembly, do not connect TOP POLES (C), MIDDLE POLES (B), and BOTTOM POLES (A) until instructed. Once connected, these will be posts for the Rack. A (5) E (10) Note that each POLE (A+B+C) has slight horizontal line indentations at 1” intervals. Each SLIP SLEEVE (E) has raised horizontal lines inside designed to lock them in place on POLE (A+B+C). On BOTTOM POLE (A), place 1 pair of SLIP SLEEVES (E) at desired height no higher than 3rd indentation from bottom.
ASSEMBLY INSTRUCTIONS STEP 3 B (5) Screw MIDDLE POLE (B) into BOTTOM POLE (A). Repeat for each remaining MIDDLE POLE (B). STEP 4 On POLE (A+B), place 1 pair of SLIP SLEEVES (E) at desired height between SHELVES (D). Please make sure arrow faces up and word “TOP” is right side up. Do this for each POLE (A+B) make sure height is identical for each POLE (A+B). E (10) D (1) Lower SHELF (D) over each MIDDLE POLE (B) so corner cylinders of SHELF (D) are positioned over SLIP SLEEVES (E).
ASSEMBLY INSTRUCTIONS STEP 5 Screw TOP POLE (C) into MIDDLE POLE (B). C (5) Repeat for each remaining TOP POLE (C). Note: Top of each TOP POLE (B) is indicated by a BLACK END CAP. STEP 6 On POLE (A+B+C), place 1 pair of SLIP SLEEVES (E) at desired height between SHELVES (D). Please make sure arrow faces up and word “TOP” is right side up. Do this for each POLE (A+B+C) and make sure height is identical for each POLE (A+B+C).
ASSEMBLY INSTRUCTIONS STEP 7 Feet Levelers are already screwed into BOTTOM POLES (A). Adjust as needed to ensure your shelving rack is level. 5 © 2019 TRINITY - 800.985.
SERVICE PARTS LIST – TBFZ-0927 Chrome Color TRINITY Customer Service provides the following replacement parts: Part Number Description Part Number Description 1) XBK-01-011-2543 Slip Sleeve 5) XBK-98-010-2535 Feet Leveler 2) ZSV-04-006-2475 Top Pole 6) ZSV-04-043-2700 Bottom Pole 3) ZSV-01-013-2523 Pole Connector 7) XBK-23-004-2517 End Cap 4) ZSV-04-007-2000 Middle Pole 8) ZSV-03-041-2718 Shelf 8 7 1 2 3 6 4 5 © 2019 TRINITY - 800.985.
SERVICE PARTS LIST – TBFPBA-0927 Black Anthracite Color TRINITY Customer Service provides the following replacement parts: Part Number Description Part Number Description 1) XBK-01-012-2543 Slip Sleeve 5) XBK-98-010-2535 Feet Leveler 2) PBA-04-006-2475 Top Pole 6) PBA-04-043-2700 Bottom Pole 3) ZSV-01-013-2523 Pole Connector 7) XBK-23-004-2517 End Cap 4) PBA-04-007-2000 Middle Pole 8) PBA-03-041-2718 Shelf 8 7 1 2 3 6 4 5 7 © 2019 TRINITY - 800.985.
WARNINGS 1. Read and understand all instructions. Failure to follow all instructions may result in injury and/or damage. 2. The warnings, cautions, and instructions discussed in this manual cannot cover all possible conditions or situations that may occur. The user must always be aware of the environment where the product will be placed and make sure to use the product in a safe and responsible manner. 3. Do NOT modify the product in any way.
PRODUCT REGISTRATION Thank you for purchasing a TRINITY PRO 4-Tier NSF Corner Wire Shelving Rack. In order to register your product and receive streamlined customer service, please fill out the following Product Registration Form and (1) fax the form to 310.347.4134 (2) complete the Product Registration Form online at www.trinityii.com or (3) scan and email the form to customerservice@trinityii.com. Include a copy of your original receipt with your submission.
1 YEAR LIMITED WARRANTY TRINITY PRO 4-Tier NSF Corner Wire Shelving Rack Model # TBFZ-0927 / TBFPBA-0927 Trinity International Industries (“Trinity”) warrants to the original consumer purchaser (“Purchaser”) of the TRINITY PRO 4-Tier NSF Corner Wire Shelving Rack (“Product”) that each Product shall be free from defects in workmanship and materials for a period of 1 year from the date of original purchase.
CONTACT US QUESTIONS? NEED PARTS? WE ARE HERE TO HELP! Please feel free to contact us. There are no questions too small, or any problems too big. We’re committed to providing our customers with the highest level of service. TRINITY Customer Service TEL: 800.985.5506 FAX: 310.347.4134 EMAIL: customerservice@trinityii.com Monday through Friday 5:00 AM – 5:00 PM (PST) www.trinityii.
