Instruction Manual

22
SPARE PARTS LIST
Weighing Hand Pallet Truck RAVAS 310
Nr
Article Number
Description
Quantity
1
899193001.3
set fork shoes
1
2
895200708
chassis
1
3
891112256 or
load cell
4
891112255
4
899172200
mounting plate load cell 6 mm
4
5
894141903
load cell mounting bolt (M12 x 35)
8
6
894141922
forkshoe mounting bolt (M12 x 60)
4
7
894142331
forkshoe mounting nut self tightening (M12)
4
8
895201705
handle (black)
1
9
895200780
pump (black)
1
10
895201799
pump repair set
1
11
895201701
steering wheel (polyurethane)
2
12
895201702
loading wheel (polyurethane tandem)
2
13
894141664
indicator support mounting bolt (M8 x 20)
3
30
892131291
touch panel with support plate
1
31
892142545.2
LCD display
1
32
892142545
indicator print board
1
33
892203003
RS232 board indicator
1
34
892203001.1
indicator adaptor bracket
1
35
892203002
indicator mounting support
1
36
894142400
butterfly nut
2
37
899193027.03
steel housing indicator
1
38
893142060
level switch 2° (approved version)
1
39
894207008
enclosure bolt (M5 x 8)
4
40
894203000
screw (KB40 x 8)
6
41
893203004
battery fixation clip
1
42
898202000
charger 230V - 12 V
1
43
893161500
load cell calibration board
1
44
893201006
plastic housing battery module
1
45
983209002
battery connection pins
2
46
893201003
fuse cover
1
47
893143606
fuse 5 x 20mm 2A
1
48
898201000
battery module 12V - 1.2Ah with handle
1
49
892132601
cable for thermal printer
1
50
892132600
thermal printer
1
51
892132604
paper roll for thermal printer
1
52
899193027.33
cover plate
1
